FTE 3110519 Clutch Slave Cylinder

Clutch Slave Cylinder for Subaru Manual Transmissions

Restore consistent clutch hydraulic operation with this FTE Slave Cylinder, part number 3110519. It is a clutch slave cylinder for Subaru manual transmission applications, with fitment covering Forester, Legacy, Outback, Baja, and Impreza models across multiple years.

Key Features

• Female connector type for the specified hydraulic connection
• External transmission bell-housing mounting location
• Acts on the clutch fork to disengage the clutch
• Not pre-filled
• No disconnect tool, O-rings, pins, or installation instructions included

Product Details

FTE 3110519 is a clutch slave cylinder used in manual transmission clutch hydraulic systems. Mounted on the outside of the transmission bell-housing, it transfers hydraulic force to the clutch fork, which works with the release bearing to separate the clutch during gear changes. This part is a direct-fit style replacement for Subaru applications including 1996-2009 Subaru Legacy, 2000-2009 Subaru Outback, 2003-2006 Subaru Baja, 1998-2005 Subaru Impreza, and 1998-2012 or 2014-2015 Subaru Forester. This part cross-references LuK LSC337 and Sachs SH6218 for the same application. Part number 3110519 is built for drivers and technicians servicing Subaru clutch hydraulic systems that require a female connector and an unfilled cylinder.

Common Problems This Part Addresses

• Soft or inconsistent clutch pedal feel
• Difficulty disengaging the clutch during shifts
• Hydraulic fluid leakage at the slave cylinder
• Clutch drag caused by weak hydraulic actuation
• Reduced clutch release performance in Subaru manual transmissions

Installation Notes

Verify connector type, mounting location, and vehicle application before installation. Because this slave cylinder is not pre-filled, the hydraulic system must be bled after installation to remove air from the line. Inspect the clutch fork, release bearing, and hydraulic line condition during service to confirm proper clutch operation after replacement.

Quality Assurance

FTE clutch hydraulic components are engineered for manual transmission service with attention to OEM-style fit and function. Valeo’s transmission systems expertise supports a product range focused on efficient power transfer and reliable clutch actuation. Use part number 3110519 when matching the correct Subaru clutch slave cylinder for the listed applications.
