Gabriel 49178 Suspension Shock Absorber - Rear

Overview

Gabriel HiJackers 49178 is an air-adjustable suspension shock absorber for rear applications on select Ford vans and trucks. It is built for temporary towing and short-term heavy loads, with leveling support that helps reduce bottoming-out while maintaining controlled handling.

Key Features

• Air-adjustable design for load leveling support
• Helps improve handling under added weight
• Rated for up to 1,100 lbs. per pair of leveling capacity
• Super-finished chromed piston rod for corrosion resistance
• Leak-proof piston seal for extended service life
• Lower eyelet and upper stud mounting configuration

Detailed Description

Gabriel HiJackers 49178 is part of the HiJackers product line, Gabriel’s air-adjustable shock family for vehicles that need temporary load support without changing the suspension system. This rear suspension shock absorber is designed for Ford E-350 Super Duty, Ford E-450 Super Duty, Ford E-150, Ford E-250, and related Econoline and Club Wagon applications listed in the fitment data. The part number 49178 is associated with rear fitments across multiple Ford platforms, including Ford E-350 Super Duty and Ford E-150 Econoline applications.

With a collapsed length of 13.89 inches and an extended length of 23.12 inches, this shock absorber uses a lower eyelet and upper stud mounting style. Gabriel’s chromed piston rod and leak-resistant seal are specified to support corrosion resistance and longer product life. The part number 49178 is a direct reference for buyers searching for a Gabriel HiJackers rear shock absorber for Ford van and truck applications.

Common Uses

• Rear sag from towing or hauling
• Bottoming-out under added cargo weight
• Reduced handling control when the vehicle is loaded
• Need for adjustable rear ride height support
• Wear from repeated short-term heavy-load use

Installation Notes

Verify rear fitment by year, model, and notes before ordering. Some applications list exclusions such as lift kits, cutaway chassis, or specific serial-number requirements. Mounting uses a lower eyelet and upper stud configuration, so confirm the existing attachment points match the part before installation.

Quality Assurance

Gabriel HiJackers are engineered with a chromed piston rod and leak-proof piston seal to support corrosion resistance and service life. This product is intended for temporary towing or short-term heavy loads and should not be used to exceed the vehicle GVWR.
