Gates 34048 Engine Coolant Thermostat
| Brand | Gates 34048 |
|---|---|
| Outlet Outside Diameter | 1.25 |
| Bolt Hole Quantity | 3 |
| Type | Integrated housing thermostat |
| Jiggle Pin Weep Hole | Yes |
| Start to Open Temperature | 172 |
| Start to Open Temperature | 78 |
| Outlet Inside Diameter | 1.05 |
| Electric | No |
| 9841 | 1 |
| Check Valve | No |
| Electric | No |
| Jiggle Pin/Check Valve | Yes |
| Number of Bolt Holes | 3 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| OE Comparison Rating | Oe performance |
| OE Exact | No |
| Outlet Inside Diameter 1 (in) | 1.05 |
| Outlet Outside Diameter 1 (in) | 1.25 |
| Temperature (C) | 78 |
| Product line | Integrated Housing Thermostat |
| Fits | Acura and Honda · 31 vehicles |
Integrated housing design. Combines the thermostat and housing for a streamlined cooling system service part.
OE temperature control. Opens at 172 degrees Fahrenheit to match the listed factory specification.
Air management features. Includes a jiggle pin weep hole and check-valve design for cooling system venting.
Cross-references Dorman - Conduct-Tite 85938, Dorman - OE Solutions 902-788 and Gates 34048 for the same application. See all 11.
Integrated thermostat housing replacement
The Gates 34048 is an integrated housing thermostat built for direct temperature control in cooling systems that use a combined thermostat and housing design. It is listed for Acura and Honda applications, including Civic, CR-V, ILX, RDX, CSX, and TSX models.
- Integrated housing thermostat design for a combined service part.
- Opens at 172 degrees Fahrenheit for OE temperature control.
- Jiggle pin weep hole and check-valve design for air management.
- Three bolt holes and one seal listed in the product attributes.
- Gates 34048 is an OE performance replacement for cooling system service.
Fitment details
Compatible With Acura and Honda applications that use this integrated thermostat housing configuration. Fits 2013-2015 Acura ILX, N/A. Fits 2012 Acura RDX, N/A. Fits 2007-2010 Acura CSX, N/A. Fits 2004-2008 Acura TSX, N/A. Fits 2006-2015 Honda Civic, N/A. Fits 2007-2014 Honda CR-V, N/A.
This part cross-references Dorman OE Solutions (e.g., 902-788) and Stant (e.g., 48747) for the same application.
Installation notes
Verify the outlet dimensions, bolt-hole count, and thermostat temperature before installation. Confirm the cooling system uses an integrated housing thermostat and match the application notes for the correct OE temperature specification.
Quality assurance
Gates develops aftermarket thermostat solutions for integrated housing applications and positions this part as an OE performance alternative to dealership replacement.
| Year | Make | Model | Liters | Cylinders | Fuel Type | Notes |
|---|---|---|---|---|---|---|
| 2015 | Acura | ILX | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2015 | Honda | Civic | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2014 | Acura | ILX | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2014 | Honda | Civic | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2014 | Honda | CR-V | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2013 | Acura | ILX | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2013 | Honda | Civic | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2013 | Honda | CR-V | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2012 | Acura | RDX | 2.3L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2012 | Honda | Civic | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2012 | Honda | CR-V | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2011 | Honda | Civic | 2.0L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2011 | Honda | CR-V | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2010 | Acura | CSX | 2.0L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2010 | Honda | Civic | 2.0L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2010 | Honda | CR-V | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2009 | Acura | CSX | 2.0L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2009 | Honda | Civic | 2.0L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2009 | Honda | CR-V | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2008 | Acura | CSX | 2.0L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2008 | Acura | TSX | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2008 | Honda | Civic | 2.0L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2008 | Honda | CR-V | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2007 | Acura | CSX | 2.0L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2007 | Acura | TSX | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2007 | Honda | Civic | 2.0L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2007 | Honda | CR-V | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2006 | Acura | TSX | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2006 | Honda | Civic | 2.0L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2005 | Acura | TSX | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
| 2004 | Acura | TSX | 2.4L | L4 | GAS | 172 Degree; OE Temperature; Seal included; Integrated Housing Thermostat |
