Gates FCM108K Engine Cooling Fan Module

Engine Cooling Control for Select Volvo and Ford Applications

The Gates FCM108K engine cooling fan module regulates electric cooling fan speed to help maintain stable engine coolant temperature. It is built for 12-volt systems with a 35-amp rating and includes a wire harness for applications that call for a direct module-and-harness solution.

Use this Gates Engine Cooling Fan Module when servicing cooling systems on select Volvo XC60, Volvo S80, and Ford Edge applications that rely on electronic fan control. The FCM108K is also listed for Lincoln MKX, Volvo V60, Volvo XC70, Volvo V70, Volvo S60, and Land Rover LR2 coverage in specific solution-kit configurations.

Key Features

• Gates FCM108K engine cooling fan module
• 12-volt electrical design
• 35-amp amperage rating
• Three female connectors with 2-pin connector circuits
• Metal/plastic housing construction
• Wire harness included
• Compact module size: 5.3 in. x 3.9 in. x 1.3 in.
• Engineered for vehicles using electronically controlled cooling fans

Product Details

Gates Engine Cooling Fan Module FCM108K is used in cooling systems where the fan module manages fan speed based on engine temperature demand. By controlling fan operation electronically, the module helps keep coolant temperature within a steady operating range while reducing unnecessary electrical load. This makes it a direct-fit service part for many late-model Ford, Lincoln, Volvo, and Land Rover cooling system repairs, including 2007-2014 Ford Edge, 2007-2015 Lincoln MKX, and 2010-2016 Volvo XC60 applications.

This part cross-references Dorman - OE Solutions 902-422 and Carlson 16234 for the same application. Gates FCM108K is also referenced under Gates FCM108 in interchange listings.

Common Problems This Part Can Address

• Cooling fan runs at the wrong speed or cycles inconsistently
• Engine temperature rises during idle or stop-and-go driving
• Cooling fan operation becomes intermittent
• Fault codes related to fan control module performance
• Loss of proper electric fan control after module failure

Installation Notes and Fitment

Fits 2007-2014 Ford Edge, N/A; Solution Kit with Trailer Tow Package including Control Module and Wiring Harness; Engine Cooling Fan Module.

Fits 2009 Ford Flex, N/A; Solution Kit; Includes Control Module & Wiring Harness; Engine Cooling Fan Module.

Fits 2007-2015 Lincoln MKX, N/A; Solution Kit with Trailer Tow Package including Control Module and Wiring Harness; Engine Cooling Fan Module.

Fits 2010-2016 Volvo XC60, N/A; Solution Kit; Engine Cooling Fan Module.

Fits 2010-2015 Volvo XC60, N/A; Solution Kit; W/Dual Fans; Engine Cooling Fan Module.

Fits 2009-2015 Volvo XC70, N/A; Solution Kit; W/Dual Fans; Engine Cooling Fan Module.

Fits 2008-2014 Volvo S80, N/A; Solution Kit; W/Dual Fans; Engine Cooling Fan Module.

Fits 2007-2015 Volvo S80, N/A; Solution Kit; Engine Cooling Fan Module.

Fits 2011-2014 Volvo S60, N/A; Solution Kit; Engine Cooling Fan Module.

Fits 2015 Volvo S60, N/A; Solution Kit; W/Dual Fans; Engine Cooling Fan Module.

Fits 2015-2016 Volvo V60, N/A; Solution Kit; Engine Cooling Fan Module.

Fits 2008-2010 Volvo V70, N/A; Solution Kit; W/Dual Fans; Engine Cooling Fan Module.

Fits 2008-2012 Land Rover LR2, N/A; Solution Kit; W/Dual Fans; Engine Cooling Fan Module.

Verify connector count, harness routing, and module mounting location before installation. Confirm the vehicle uses a 12-volt cooling fan control setup and match the original connector style and pin count to the existing system.

Quality Assurance

Gates supplies cooling system components for service applications that require accurate fan control and OE-style fitment. The FCM108K is built to match the electrical and connector requirements listed for the supported vehicles, including Volvo XC60 and Ford Edge cooling fan module service.
