Gates TL104 Turbocharger Oil Return Line

Overview of Gates Turbocharger Oil Return Line TL104

The Gates Turbocharger Oil Return Line TL104 is engineered for reliable oil flow management in turbocharged engines. Designed specifically for Ford F-250 Super Duty and F-350 Super Duty models, this stainless steel oil feed line ensures durability and precise fitment.

• Constructed from corrosion-resistant stainless steel for long-lasting performance
• Centerline length of 28.625 inches (727 mm) for exact fitment
• Features a male coupling inlet fitting and banjo outlet fitting
• Includes 2 banjo bolts and 4 washers for complete installation
• OE exact comparison rating for direct replacement

Detailed Product Description

The TL104 Turbocharger Oil Return Line from Gates is part of the Turbocharger Oil Line product line, which focuses on delivering high-quality oil feed and return components for turbocharged systems. This line is designed to meet or exceed original equipment specifications, providing reliable oil flow and maintaining turbocharger efficiency. The stainless steel construction offers resistance to heat and corrosion, critical for the demanding environment of turbocharger oil circuits.

With a centerline length of 28.625 inches (727 mm), the TL104 ensures proper routing and fitment in Ford F-250 Super Duty and F-350 Super Duty trucks. The inlet features a male coupling fitting, while the outlet uses a banjo fitting, facilitating secure connections and leak-free operation. The included hardware—2 banjo bolts and 4 washers—supports straightforward installation.

Applications and Problem Solving

• Replaces worn or damaged turbocharger oil feed lines in Ford Super Duty trucks
• Prevents oil leaks that can lead to turbocharger failure
• Maintains proper oil flow to ensure turbocharger lubrication and cooling
• Addresses issues related to corrosion or cracking in original oil lines
• Supports restoration of turbocharger system integrity after maintenance or upgrades

Installation Notes and Tips

• Verify compatibility with Ford F-250 Super Duty and F-350 Super Duty models before installation
• Use the included banjo bolts and washers to ensure a secure, leak-free connection
• Inspect mating surfaces for cleanliness and damage prior to assembly
• Follow manufacturer torque specifications for fittings to avoid over-tightening
• Check for leaks after installation and during initial engine operation

Quality Assurance and Warranty

The Gates Turbocharger Oil Line TL104 is manufactured to meet OE exact standards, ensuring consistent quality and performance. Gates is known for rigorous testing and quality control processes. While specific warranty details are not provided here, Gates products typically come with a limited warranty against defects in materials and workmanship. Consult product documentation or authorized sources for exact warranty terms.
