GKN Loebro 306275 CV Joint Kit - Front Right Outer

OE Quality 60-Day Returns

GKN Loebro 306275 CV Joint Kit - Front Right Outer

Brand	GKN Loebro 306275
Position	Front Right Outer
Length	3.464
Grade Type	Standard replacement
Shaft Spline Quantity	42
CV Joint End 1 Outside Diameter	3.708
CV Joint End 2 Outside Diameter	3.011
CV Joint Housing Material	Cv joint; a: 42; f: 28; o [mm]: 77; machined: with groove in inte
CV Joint Housing Material	Gkn sx-cv joint;a:42t;f:28t;o:Ø76,50mm;joint:Ø94,2mm;l:88,0mm;m
Special Information	Cv joint end 2 outside dia.: cv joint; a: 42; f: 28; o [mm]: 77;
Fits	Audi · 74 vehicles

Standard replacement. Direct-fit CV joint kit for straightforward service work.

Countertrack SX design. S-shaped tracks reduce friction and heat while increasing torque capacity.

OE technology. GKN Loebro engineering is used by major automakers worldwide.

Cross-references Gates 36096, 8K0 498 099 L and 8K0498099F for the same application. See all 6.

$223.87Free shipping

In stock · usually ships same day before 1pm CST

Step 1 — Confirm fitment

Free return shipping if it doesn't fit when you check fitment here first.

Confirm position

Select your vehicle to confirm fitment

Verify this part fits before purchasing — free returns if it doesn't

Step 2 — Quantity

Free shipping to the continental U.S.

Free returns within 60 days if it doesn't fit when fitment is verified.

Not what you need? See all CV Joint Kit options

OE-Style Front Right Outer CV Joint

GKN Loebro 306275 is a standard replacement CV joint kit built with OE technology for the front right outer position. It is engineered for Audi driveline service where precise articulation, low friction, and stable torque transfer matter.

Compatible with select Audi A4, A5, A6, A6 Quattro, A7 Quattro, A8 Quattro, Q5, RS5, RS7, S4, S5, S6, S7, S8, and SQ5 applications, this part number 306275 is a direct-fit service solution for many 2011-2018 models.

Key Features

GKN Loebro CV joint kit for the front right outer axle position
Countertrack SX joint design with opposed tracks and an S-shaped track profile
Built to reduce friction and heat while supporting higher bending angles
Standard replacement grade for OE-style driveline service
Pre-lubricated and supplied with TPE boot material
42 shaft spline quantity
Cross-reference: Gates 36096

Detailed Description

GKN Loebro 306275 uses Countertrack technology developed for modern passenger vehicles, including midsize and premium Audi platforms. The joint design helps maintain smooth power delivery at the front right outer axle while supporting the articulation demands of all-wheel-drive drivetrains. Key dimensions include a 94 mm joint diameter, 88 mm length, M16x1.5 thread size, and 42 shaft splines, making this CV joint kit a precise service part for the listed applications.

This part is used on Audi A4, A5, A6, A6 Quattro, A7 Quattro, A8 Quattro, Q5, RS5, RS7, S4, S5, S6, S7, S8, and SQ5 models across 2011-2018 coverage. Part number 306275 is also referenced for OE-style service on vehicles using the same front right outer driveline configuration.

What This Part Helps Address

Clicking or popping noises during turns from a worn outer CV joint
Vibration or shudder under acceleration from driveline wear
Grease leakage caused by a damaged or aging joint assembly
Excessive play in the front right outer axle connection
Loss of smooth torque transfer through the front axle

Installation Notes and Tips

Verify axle spline count, joint diameter, and thread specification before installation. Confirm vehicle-specific fitment details such as PR code TG6, VIN breakpoints, and model-year notes for Audi A4, A6, Q5, S4, S5, SQ5, and related applications. Clean the mating surfaces thoroughly and inspect the axle shaft, boot area, and retaining hardware condition before assembly.

Quality Assurance

GKN Automotive is a long-established supplier of drive system technology, and Loebro CV joints are built around OE-level engineering used by major vehicle manufacturers. This part number 306275 reflects that driveline-focused design approach for service replacement on the listed Audi applications.

This part fits 74 vehicles

Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.

Year	Make	Model	Body Type	Liters	Cylinders	Position	Notes
2018	Audi	A7 Quattro	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2018	Audi	A8 Quattro	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2018	Audi	RS7	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2018	Audi	S7	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2018	Audi	S8	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2017	Audi	A7 Quattro	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2017	Audi	A8 Quattro	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2017	Audi	Q5	—	3.0L	V6	Front Right Outer	To VIN # FPH150000
2017	Audi	RS7	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2017	Audi	S5	Convertible	3.0L	V6	Front Right Outer	With PR Code TG6
2017	Audi	S7	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2017	Audi	S8	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2017	Audi	SQ5	—	3.0L	V6	Front Right Outer	To VIN # FPH150000
2016	Audi	A4	—	2.0L	L4	Front Right Outer	Column2 Pre-lubricated
2016	Audi	A6 Quattro	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2016	Audi	A7 Quattro	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2016	Audi	A8 Quattro	—	6.3L	W12	Front Right Outer	Column2 Pre-lubricated
2016	Audi	Q5	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2016	Audi	RS7	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2016	Audi	S4	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2016	Audi	S5	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2016	Audi	S7	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2016	Audi	S8	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2016	Audi	SQ5	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2015	Audi	A4	—	2.0L	L4	Front Right Outer	Column2 Pre-lubricated
2015	Audi	A6	—	2.0L	L4	Front Right Outer	With PR Code TG6
2015	Audi	A6 Quattro	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2015	Audi	A7 Quattro	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2015	Audi	A8 Quattro	—	6.3L	W12	Front Right Outer	Column2 Pre-lubricated
2015	Audi	Q5	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2015	Audi	RS5	—	4.2L	V8	Front Right Outer	Column2 Pre-lubricated
2015	Audi	RS7	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2015	Audi	S4	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2015	Audi	S5	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2015	Audi	S6	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2015	Audi	S7	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2015	Audi	S8	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2015	Audi	SQ5	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2014	Audi	A4	—	2.0L	L4	Front Right Outer	Column2 Pre-lubricated
2014	Audi	A5	—	2.0L	L4	Front Right Outer	Column2 Pre-lubricated
2014	Audi	A6	—	2.0L	L4	Front Right Outer	With PR Code TG6
2014	Audi	A6 Quattro	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2014	Audi	A7 Quattro	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2014	Audi	A8 Quattro	—	6.3L	W12	Front Right Outer	Column2 Pre-lubricated
2014	Audi	Q5	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2014	Audi	RS5	—	4.2L	V8	Front Right Outer	Column2 Pre-lubricated
2014	Audi	RS7	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2014	Audi	S4	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2014	Audi	S5	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2014	Audi	S6	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2014	Audi	S7	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2014	Audi	S8	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2014	Audi	SQ5	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2013	Audi	A4	—	2.0L	L4	Front Right Outer	Column2 Pre-lubricated
2013	Audi	A5	—	2.0L	L4	Front Right Outer	Column2 Pre-lubricated
2013	Audi	A6	—	2.0L	L4	Front Right Outer	With PR Code TG6
2013	Audi	A6 Quattro	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2013	Audi	A7 Quattro	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2013	Audi	A8 Quattro	—	6.3L	W12	Front Right Outer	Column2 Pre-lubricated
2013	Audi	Q5	—	3.0L	V6	Front Right Outer	From 02/04/2013
2013	Audi	RS5	—	4.2L	V8	Front Right Outer	Column2 Pre-lubricated
2013	Audi	S4	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2013	Audi	S5	—	3.0L	V6	Front Right Outer	Column2 Pre-lubricated
2013	Audi	S6	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2013	Audi	S7	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2013	Audi	S8	—	4.0L	V8	Front Right Outer	Column2 Pre-lubricated
2012	Audi	A4	—	2.0L	L4	Front Right Outer	From 11/07/2011
2012	Audi	A5	—	2.0L	L4	Front Right Outer	From 11/07/2011
2012	Audi	A6	—	2.0L	L4	Front Right Outer	From 11/14/2011
2012	Audi	A6 Quattro	—	3.0L	V6	Front Right Outer	With PR Code TG6
2012	Audi	A7 Quattro	—	3.0L	V6	Front Right Outer	To 11/14/2011
2012	Audi	A8 Quattro	—	6.3L	W12	Front Right Outer	Column2 Pre-lubricated
2012	Audi	S4	—	3.0L	V6	Front Right Outer	With PR Code TG6
2011	Audi	A8 Quattro	—	4.2L	V8	Front Right Outer	From 09/06/2010
No rows match your filter.

Directly replaces or cross-references 6 part numbers

Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.

Gates — 360968K0 498 099 L8K0498099F8K0498099FX803103VKJA 3115
