GKN Loebro 306277 CV Joint Kit
OE Quality 60-Day Returns
GKN Loebro

GKN Loebro 306277 CV Joint Kit

Brand GKN Loebro 306277
Position Front Right Outer, Front, Front Outer, and Front Left Outer
Length 3.472
Grade Type Standard replacement
Shaft Spline Quantity 42
CV Joint End 1 Outside Diameter 3.708
CV Joint End 2 Outside Diameter 2.637
CV Joint Housing Material Cv joint; a: 42; f: 28; o [mm]: 67; machined: with groove in inte
CV Joint Housing Material Gkn sx-cv joint;a:42t;f:28t;o:Ø67,00mm;joint:Ø94,2mm;l:88,2mm;m
Special Information Cv joint end 2 outside dia.: cv joint; a: 42; f: 28; o [mm]: 67;
Fits Audi · 144 vehicles

Countertrack SX design. S-shaped track geometry helps reduce friction and heat in driveline service.

OE-focused engineering. Built with GKN technology used by major vehicle manufacturers.

Standard replacement. Service-grade CV joint kit for driveline repair applications.

Cross-references FEL-PRO 36098, 4M0498099 and 8W0498099D for the same application. See all 4.

$135.79Free shipping
In stock · usually ships same day before 1pm CST
Step 1 — Confirm fitment
Free return shipping if it doesn't fit when you check fitment here first.

Select your vehicle to confirm fitment
Verify this part fits before purchasing — free returns if it doesn't
Step 2 — Quantity
Order total $135.79
Free shipping to the continental U.S.
Free returns within 60 days if it doesn't fit when fitment is verified.
Not what you need? See all CV Joint Kit options

OE-Style CV Joint Kit

This GKN Loebro CV joint kit is built around Countertrack SX technology for precise driveline service. It is a standard replacement part for Audi applications that require a front or front outer CV joint with OE-style engineering.

  • Countertrack SX design uses opposed tracks to reduce friction and heat.
  • Supports higher torque transfer and a larger bending angle than conventional joint layouts.
  • Includes a dust cover and pre-lubricated joint construction.
  • Uses a 42-spline shaft and M16x1.5 thread specification.
  • Standard replacement grade for service work on driveline assemblies.

Product Details

GKN Loebro 306277 is engineered with the brand’s Countertrack SX joint profile, which uses an S-shaped track layout to improve motion efficiency in compact driveline packaging. The design is used across a wide range of Audi fitments, including Audi A4 Quattro, Audi A6 Quattro, and Audi Q7 applications that call for front or front outer service. Part number 306277 is specified for multiple model years and positions, including front outer and front right outer configurations, so fitment should be matched carefully to the exact vehicle listing.

This part cross-references FEL-PRO 36098 for the same application.

Common Repair Uses

  • Clicking or popping during turns from a worn outer CV joint.
  • Vibration or shudder under acceleration from driveline wear.
  • Grease leakage caused by a damaged joint boot or seal area.
  • Excess play in the joint that affects smooth power delivery.
  • Noise from a fatigued joint in front axle service.

Installation Notes

Confirm the exact Audi model, year, and position before ordering, since this part is listed for multiple front and front outer applications. Match the spline count, thread size, and joint dimensions to the original component during service. Professional installation is recommended for driveline repair work.

Quality Assurance

GKN Automotive supplies drive system technology to major vehicle manufacturers, and the Loebro Countertrack SX joint reflects that OE-focused engineering approach. Part number 306277 is a standard replacement CV joint kit built for service accuracy and consistent driveline operation.

Related reading

This part fits 144 vehicles
Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
YearMakeModelBody TypeLitersCylindersFuel TypePositionNotes
2026AudiA6 allroad—3.0LV6—Front OuterColumn2 42 mm
2026AudiA8 Quattro—3.0LV6MILD HYBRID EV-GAS (MHEV)Front OuterColumn2 42 mm
2026AudiQ7—3.0LV6MILD HYBRID EV-GAS (MHEV)Front OuterColumn2 42 mm
2026AudiQ8—3.0LV6—Front OuterColumn2 42 mm
2026AudiS8—4.0LV8MILD HYBRID EV-GAS (MHEV)Front OuterColumn2 42 mm
2026AudiSQ7—4.0LV8—Front OuterColumn2 42 mm
2026AudiSQ8—4.0LV8—Front OuterColumn2 42 mm
2025AudiA4 allroad—2.0LL4—FrontColumn2 Pre-lubricated
2025AudiA4 Quattro—2.0LL4—FrontColumn2 Pre-lubricated
2025AudiA5 SportbackHatchback2.0LL4—Front OuterWith uncoupling rear differential [GH4]
2025AudiA6 allroad—3.0LV6—Front OuterColumn2 Pre-lubricated
2025AudiA6 Quattro—3.0LV6—Front OuterColumn2 Pre-lubricated
2025AudiA7 Sportback—3.0LV6—Front OuterColumn2 Pre-lubricated
2025AudiA8 Quattro—3.0LV6—Front OuterColumn2 Pre-lubricated
2025AudiQ7—3.0LV6—Front OuterColumn2 Pre-lubricated
2025AudiQ8—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2025AudiRS5 Sportback—2.9LV6—Front OuterColumn2 Pre-lubricated
2025AudiS4—3.0LV6—FrontColumn2 Pre-lubricated
2025AudiS5 Sportback—3.0LV6—FrontColumn2 Pre-lubricated
2025AudiS6—2.9LV6—Front OuterColumn2 Pre-lubricated
2025AudiS7 Sportback—2.9LV6—Front OuterColumn2 Pre-lubricated
2025AudiS8—4.0LV8—Front OuterColumn2 Pre-lubricated
2025AudiSQ5—3.0LV6—Front OuterColumn2 Pre-lubricated
2025AudiSQ5 Sportback—3.0LV6—Front OuterColumn2 Pre-lubricated
2024AudiA4 allroad—2.0LL4—FrontColumn2 Pre-lubricated
2024AudiA4 Quattro—2.0LL4—FrontColumn2 Pre-lubricated
2024AudiA5 Quattro—2.0LL4—FrontColumn2 Pre-lubricated
2024AudiA5 SportbackHatchback2.0LL4—Front OuterWith uncoupling rear differential [GH4]
2024AudiA6 allroad—3.0LV6—Front OuterColumn2 Pre-lubricated
2024AudiA6 Quattro—3.0LV6—Front OuterColumn2 Pre-lubricated
2024AudiA7 Sportback—3.0LV6—Front OuterColumn2 Pre-lubricated
2024AudiA8 Quattro—3.0LV6—Front OuterColumn2 Pre-lubricated
2024AudiQ7—3.0LV6—Front OuterColumn2 Pre-lubricated
2024AudiQ8—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2024AudiRS5—2.9LV6—Front OuterColumn2 Pre-lubricated
2024AudiRS5 Sportback—2.9LV6—Front OuterColumn2 Pre-lubricated
2024AudiS4—3.0LV6—FrontColumn2 Pre-lubricated
2024AudiS5—3.0LV6—FrontColumn2 Pre-lubricated
2024AudiS5 Sportback—3.0LV6—FrontColumn2 Pre-lubricated
2024AudiS6—2.9LV6—Front OuterColumn2 Pre-lubricated
2024AudiS7 Sportback—2.9LV6—Front OuterColumn2 Pre-lubricated
2024AudiS8—4.0LV8—Front OuterColumn2 Pre-lubricated
2024AudiSQ5—3.0LV6—Front OuterColumn2 Pre-lubricated
2024AudiSQ5 Sportback—3.0LV6—Front OuterColumn2 Pre-lubricated
2023AudiA4 allroad—2.0LL4—FrontColumn2 Pre-lubricated
2023AudiA4 Quattro—2.0LL4—FrontColumn2 Pre-lubricated
2023AudiA5 Quattro—2.0LL4—FrontColumn2 Pre-lubricated
2023AudiA5 Sportback—2.0LL4—FrontColumn2 Pre-lubricated
2023AudiA6 allroad—3.0LV6—Front OuterColumn2 Pre-lubricated
2023AudiA6 Quattro—3.0LV6—Front OuterColumn2 Pre-lubricated
2023AudiA7 Sportback—3.0LV6—Front OuterColumn2 Pre-lubricated
2023AudiA8 Quattro—3.0LV6—Front OuterFrom 07/04/2022
2023AudiQ7—3.0LV6—Front OuterColumn2 Pre-lubricated
2023AudiQ8—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2023AudiRS5—2.9LV6—Front OuterColumn2 Pre-lubricated
2023AudiRS5 Sportback—2.9LV6—Front OuterColumn2 Pre-lubricated
2023AudiS4—3.0LV6—FrontColumn2 Pre-lubricated
2023AudiS5—3.0LV6—FrontColumn2 Pre-lubricated
2023AudiS5 SportbackHatchback3.0LV6—Front OuterColumn2 Pre-lubricated
2023AudiS6—2.9LV6—Front OuterColumn2 Pre-lubricated
2023AudiS7 Sportback—2.9LV6—Front OuterColumn2 Pre-lubricated
2023AudiS8—4.0LV8—Front OuterColumn2 Pre-lubricated
2023AudiSQ5—3.0LV6—Front OuterFrom 09/19/2022
2023AudiSQ5 Sportback—3.0LV6—Front OuterFrom 09/19/2022
2022AudiA4 allroad—2.0LL4—FrontColumn2 Pre-lubricated
2022AudiA4 Quattro—2.0LL4—FrontColumn2 Pre-lubricated
2022AudiA5 Quattro—2.0LL4—FrontColumn2 Pre-lubricated
2022AudiA5 Sportback—2.0LL4—FrontColumn2 Pre-lubricated
2022AudiA6 allroad—3.0LV6—Front OuterColumn2 Pre-lubricated
2022AudiA6 Quattro—3.0LV6—Front OuterColumn2 Pre-lubricated
2022AudiA7 Sportback—3.0LV6—Front OuterColumn2 Pre-lubricated
2022AudiA8 Quattro—3.0LV6—FrontColumn2 Pre-lubricated
2022AudiQ7—3.0LV6—Front OuterColumn2 Pre-lubricated
2022AudiQ8—3.0LV6—FrontColumn2 Pre-lubricated
2022AudiRS5—2.9LV6—Front OuterColumn2 Pre-lubricated
2022AudiRS5 Sportback—2.9LV6—Front OuterColumn2 Pre-lubricated
2022AudiS4—3.0LV6—FrontColumn2 Pre-lubricated
2022AudiS5Coupe3.0LV6—FrontColumn2 Pre-lubricated
2022AudiS5 SportbackHatchback3.0LV6—FrontColumn2 Pre-lubricated
2022AudiS6—2.9LV6—Front OuterColumn2 Pre-lubricated
2022AudiS7 Sportback—2.9LV6—Front OuterColumn2 Pre-lubricated
2022AudiS8—4.0LV8—FrontColumn2 Pre-lubricated
2021AudiA4 allroad—2.0LL4—FrontColumn2 Pre-lubricated
2021AudiA4 Quattro—2.0LL4—FrontColumn2 Pre-lubricated
2021AudiA5 Quattro—2.0LL4—FrontColumn2 Pre-lubricated
2021AudiA5 Sportback—2.0LL4—Front Right OuterWith uncoupling rear differential
2021AudiA6 allroad—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2021AudiA6 Quattro—3.0LV6—Front OuterColumn2 Pre-lubricated
2021AudiA7 Sportback—3.0LV6—Front OuterColumn2 Pre-lubricated
2021AudiA8 Quattro—4.0LV8—FrontColumn2 Pre-lubricated
2021AudiQ7—3.0LV6—FrontColumn2 Pre-lubricated
2021AudiQ8—3.0LV6—FrontWith rear differential
2021AudiRS5—2.9LV6—Front Right OuterColumn2 Pre-lubricated
2021AudiRS5 Sportback—2.9LV6—Front Right OuterColumn2 Pre-lubricated
2021AudiS4—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2021AudiS5—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2021AudiS5 Sportback—3.0LV6—Front Left OuterColumn2 Pre-lubricated
2021AudiS6—2.9LV6—Front Right OuterColumn2 Pre-lubricated
2021AudiS7 Sportback—2.9LV6—Front Right OuterColumn2 Pre-lubricated
2021AudiS8—4.0LV8—FrontColumn2 Pre-lubricated
2020AudiA4 allroad—2.0LL4—Front Right OuterColumn2 Pre-lubricated
2020AudiA4 Quattro—2.0LL4—Front Right OuterColumn2 Pre-lubricated
2020AudiA5 QuattroCoupe2.0LL4—Front Right OuterColumn2 Pre-lubricated
2020AudiA5 Sportback—2.0LL4—Front Right OuterColumn2 Pre-lubricated
2020AudiA6 allroad—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2020AudiA6 Quattro—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2020AudiA7 Sportback—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2020AudiA8 Quattro—4.0LV8—Front Right OuterColumn2 Pre-lubricated
2020AudiQ7—2.0LL4—Front Right OuterColumn2 Pre-lubricated
2020AudiQ8—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2020AudiS4—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2020AudiS5—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2020AudiS5 Sportback—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2020AudiS6—2.9LV6—Front Right OuterColumn2 Pre-lubricated
2020AudiS7 Sportback—2.9LV6—Front Right OuterColumn2 Pre-lubricated
2020AudiS8—4.0LV8—Front Right OuterWith rear differential
2019AudiA4 allroad—2.0LL4—Front Right OuterColumn2 Pre-lubricated
2019AudiA4 Quattro—2.0LL4—Front Right OuterColumn2 Pre-lubricated
2019AudiA5 QuattroCoupe2.0LL4—Front Right OuterColumn2 Pre-lubricated
2019AudiA5 Sportback—2.0LL4—Front Right OuterColumn2 Pre-lubricated
2019AudiA6 Quattro—3.0LV6—Front Right OuterWith rear differential
2019AudiA7 Sportback—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2019AudiA8 Quattro—4.0LV8—Front Right OuterColumn2 Pre-lubricated
2019AudiQ7—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2019AudiQ8—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2019AudiRS5—2.9LV6—Front Right OuterColumn2 Pre-lubricated
2019AudiRS5 Sportback—2.9LV6—Front Right OuterColumn2 Pre-lubricated
2019AudiS4—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2019AudiS5—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2019AudiS5 Sportback—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2018AudiA4 allroad—2.0LL4—Front Right OuterColumn2 Pre-lubricated
2018AudiA4 Quattro—2.0LL4—Front Right OuterColumn2 Pre-lubricated
2018AudiA5 QuattroCoupe2.0LL4—Front Right OuterColumn2 Pre-lubricated
2018AudiA5 Sportback—2.0LL4—Front Right OuterColumn2 Pre-lubricated
2018AudiQ7—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2018AudiRS5—2.9LV6—Front Right OuterColumn2 Pre-lubricated
2018AudiS4—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2018AudiS5—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2018AudiS5 Sportback—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2017AudiA4 allroad—2.0LL4—Front Right OuterColumn2 Pre-lubricated
2017AudiA4 Quattro—2.0LL4—Front Right OuterColumn2 Pre-lubricated
2017AudiA5 QuattroCoupe2.0LL4—Front Right OuterColumn2 Pre-lubricated
2017AudiQ7—3.0LV6—Front Right OuterColumn2 Pre-lubricated
2017AudiS5Coupe3.0LV6—Front Right OuterColumn2 Pre-lubricated
Directly replaces or cross-references 4 part numbers
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
FEL-PRO — 360984M04980998W0498099D760 498 099 X
