Global Parts 13191C Radiator

Overview of Global Parts Radiator 13191C for Hyundai and Kia

The Global Parts radiator 13191C is designed specifically for select Hyundai and Kia models, including the Azera, Cadenza, Optima, and Sonata. Engineered with a cross flow design and integrated transmission oil cooler, this radiator supports efficient engine cooling and transmission performance.

• Core dimensions: 18.19 inches height, 25 inches width, 0.56 inches thickness
• Core material: durable aluminum for effective heat dissipation
• Plastic tank construction for corrosion resistance
• Includes transmission oil cooler with tube fittings and 13.78-inch distance between fittings
• Single core row with 78 fins per 4 inches for optimized airflow
• Inlet diameter: 1.38 inches; outlet diameter: 1.4 inches
• Compatible with Hyundai Azera, Kia Cadenza, Optima, and Sonata models

Technical Details and Specifications

The Global Parts radiator 13191C features a cross flow core design that enhances cooling efficiency by allowing coolant to flow horizontally through the core. The aluminum core measures 462.03 mm in height, 635 mm in width, and 14.22 mm in thickness, providing a balance of strength and heat transfer capability. The plastic tanks reduce weight and resist corrosion, extending the radiator's service life. This radiator includes a built-in transmission oil cooler with tube fittings spaced 13.78 inches apart, supporting transmission fluid cooling without the need for additional components. The inlet and outlet diameters of 35.05 mm and 35.56 mm respectively ensure proper hose fitment and fluid flow. With 78 fins every 4 inches, the radiator maximizes airflow to maintain optimal engine temperatures.

Applications and Problem Solving

• Replaces faulty or leaking radiator in Hyundai Azera, Kia Cadenza, Optima, and Sonata
• Addresses engine overheating issues caused by inefficient cooling
• Resolves transmission overheating by integrating a transmission oil cooler
• Eliminates coolant leaks from damaged or corroded radiator tanks
• Improves overall engine performance by maintaining stable operating temperatures

Installation Notes and Tips

When installing the Global Parts radiator 13191C, ensure compatibility with your vehicle’s make and model. Properly connect the transmission oil cooler fittings using the specified tube fitting type and verify the 13.78-inch spacing between fittings. Inspect all hose connections for secure fitment to the 1.38-inch inlet and 1.4-inch outlet diameters. Bleed the cooling system thoroughly after installation to prevent air pockets and ensure efficient coolant circulation. It is recommended to replace any worn hoses or clamps during installation to maintain system integrity.

Quality Assurance and Warranty

Global Parts manufactures the 13191C radiator to meet OEM specifications for Hyundai and Kia vehicles. The use of aluminum core and plastic tanks provides durability and corrosion resistance. This radiator includes a transmission oil cooler designed to OEM standards for reliable performance. While specific warranty details are not provided here, Global Parts products typically come with a limited warranty covering defects in materials and workmanship. Verify warranty terms with the distributor or installer prior to purchase.
