Global Parts 1696C Radiator

Overview of Global Parts Radiator 1696C for Chevrolet and GMC Trucks

The Global Parts radiator part number 1696C is designed specifically for Chevrolet and GMC truck models including C35, C1500, C2500, C2500 Suburban, C3500, K1500, K2500, K2500 Suburban, and K3500. This radiator features a durable aluminum core and plastic tanks, engineered to provide reliable cooling performance for your vehicle's engine and transmission.

• Core dimensions: 19.75 inches height, 34 inches width, 2.25 inches thickness
• Aluminum core material for efficient heat dissipation
• Plastic tank construction for corrosion resistance
• Includes integrated transmission oil cooler with adapter fittings spaced 11.5 inches apart
• Engine oil cooler included with fittings also spaced 11.5 inches apart
• Cross flow design for optimized coolant flow
• Single core row with 41 fins per 4 inches for effective cooling
• Inlet diameter: 1.31 inches; outlet diameter: 1.6 inches

Detailed Product Description

The Global Parts 1696C radiator is engineered to meet the cooling demands of heavy-duty Chevrolet and GMC trucks. Its aluminum core measures 19.75 inches in height, 34 inches in width, and 2.25 inches in thickness, providing a robust surface area for heat exchange. The plastic tanks offer resistance to corrosion and reduce overall weight. This radiator features a cross flow design, which enhances coolant circulation and heat dissipation efficiency.

Additionally, the radiator includes both transmission and engine oil coolers, each with fittings spaced 11.5 inches apart and adapter-type fittings for easy connection. The single core row construction with 41 fins per 4 inches ensures consistent airflow and cooling performance under demanding conditions. The inlet and outlet diameters of 1.31 inches and 1.6 inches respectively are designed to match OEM specifications for a direct fit.

Compatible Vehicles and Applications

• Chevrolet C35, C1500, C2500, C2500 Suburban, C3500
• GMC K1500, K2500, K2500 Suburban, K3500

This radiator is intended for use in maintaining optimal engine and transmission temperatures, especially in trucks used for towing, hauling, or heavy-duty applications.

Common Issues Addressed by This Radiator

• Overheating due to worn or damaged radiator cores
• Transmission fluid overheating from faulty or missing transmission oil coolers
• Engine oil temperature regulation problems
• Leaks caused by cracked plastic tanks or corroded aluminum cores
• Reduced cooling efficiency from clogged or bent fins

Installation Notes and Tips

• Verify compatibility with your specific Chevrolet or GMC truck model before installation
• Ensure all hose connections match the 1.31 inch inlet and 1.6 inch outlet diameters
• Check transmission and engine oil cooler fittings for proper adapter type and spacing (11.5 inches)
• Inspect mounting points and brackets for secure fitment
• Flush cooling system prior to installation to prevent contamination

Quality Assurance and Warranty

Global Parts radiators are manufactured to meet or exceed OEM standards for durability and performance. The use of aluminum cores and plastic tanks balances corrosion resistance with structural integrity. This radiator includes integrated transmission and engine oil coolers to support vehicle longevity. Warranty coverage details should be confirmed with the distributor or manufacturer, as they may vary by region.
