Global Parts 1711744 A/C Compressor Cut-Out Switch

Global Parts A/C Compressor Cut-Off Switch

Global Parts Part Number 1711744 is an A/C compressor cut-off switch used in HVAC pressure control systems. It provides feedback to the engine management system and, on earlier vehicles, can directly shut the compressor off to help prevent compressor damage from excessive pressure.

• HVAC pressure switch for A/C compressor cut-off or cut-out control
• Supports engine management feedback on modern vehicle systems
• Used in high-side pressure monitoring applications
• Direct replacement for select Audi and Cadillac applications
• Cross-references Four Seasons 36678 and UAC SW11159C for the same application

Application Details

Compatible With 1995-2002 Cadillac Eldorado, high side switch; 1995-2000 Cadillac DeVille, high side switch; 1995-1999 Cadillac Seville, high side switch; 1994-1998 Audi Cabriolet, A/C compressor cut-out switch; 1995-1997 Audi S6, A/C compressor cut-out switch; 1995 Audi A6, A/C compressor cut-out switch; 1995 Audi A6 Quattro, A/C compressor cut-out switch; 1994 Audi 100, HVAC pressure switch - high pressure cutout; 1994 Audi 100 Quattro, HVAC pressure switch - high pressure cutout; and 1994 Audi V8 Quattro, A/C compressor cut-out switch. Part number 1711744 is listed for select Cadillac Eldorado, Cadillac DeVille, and Cadillac Seville models, as well as several Audi applications.

What It Helps Address

• A/C compressor cycling caused by high system pressure
• Compressor shutdown triggered by pressure protection logic
• Loss of HVAC feedback to the ECM
• Faulty high-side pressure switch operation
• Intermittent A/C compressor cut-off behavior

Installation Notes

Verify the original switch style, connector, and pressure-switch location before installation. This part is used in high-side pressure control circuits, so confirm the vehicle’s HVAC diagnosis and refrigerant system condition before replacing the switch. Match the application by year, make, and model, including the specific notes shown for Cadillac and Audi fitments.

Quality Assurance

Global Parts supplies this switch as an OE-style HVAC electrical component for the listed applications. Part Number 1711744 is built for pressure-based compressor control in systems that rely on switch feedback to manage A/C operation.
