Global Parts 2608C Radiator

Overview of Global Parts Radiator 2608C

The Global Parts radiator 2608C is engineered for reliable cooling performance in select Chevrolet, Pontiac, and Saturn vehicles. Designed with a cross flow core and integrated transmission oil cooler, this radiator supports efficient engine temperature management for models like the Chevrolet Cobalt, Pontiac G5, Saturn Ion, and Pursuit.

• Core dimensions: 14.5 inches height, 26.75 inches width, 0.63 inches thickness
• Core material: durable aluminum for effective heat dissipation
• Plastic tank construction for corrosion resistance
• Includes transmission oil cooler with 11.5-inch fitting spacing
• Single core row with 73 fins per 4 inches for optimized airflow
• Inlet diameter: 1.38 inches; outlet diameter: 1.4 inches
• Cross flow design enhances coolant circulation

Detailed Product Description

The Global Parts 2608C radiator features a robust aluminum core measuring 368.3 mm in height and 679.45 mm in width, with a thickness of 16 mm. Its single-row core design incorporates 73 fins every 4 inches, promoting efficient heat exchange. The plastic tanks provide resistance against corrosion and wear, extending the radiator's service life. This radiator also includes a built-in transmission oil cooler, with fittings spaced 11.5 inches apart, supporting vehicles that require integrated transmission cooling. The cross flow configuration improves coolant flow across the core, enhancing overall cooling efficiency. The inlet and outlet diameters of approximately 35 mm ensure compatibility with factory hose connections on Chevrolet Cobalt, Pontiac G5, Saturn Ion, and Pursuit models.

Compatible Vehicles and Applications

This radiator is compatible with the following makes and models:

• Chevrolet Cobalt
• Pontiac G5
• Saturn Ion
• Saturn Pursuit

It is designed to replace original equipment radiators in these vehicles, providing reliable cooling and transmission oil cooling where applicable.

Common Issues Addressed by Radiator 2608C

• Engine overheating due to inefficient heat dissipation
• Transmission fluid overheating in vehicles with integrated transmission coolers
• Leaks or cracks in original radiator tanks
• Reduced cooling performance from clogged or damaged fins
• Corrosion-related radiator failure

Installation Notes and Tips

• Ensure compatibility with vehicle make and model before installation
• Inspect and replace all hoses and clamps during radiator replacement
• Flush the cooling system to remove debris and contaminants
• Check transmission cooler lines for leaks if applicable
• Follow manufacturer torque specifications for mounting hardware

Quality Assurance and Warranty

Global Parts radiators are manufactured to meet or exceed OEM specifications, using quality aluminum cores and durable plastic tanks. The 2608C radiator undergoes rigorous testing to ensure proper fitment and performance. Warranty coverage details should be confirmed with the distributor or retailer at the time of purchase.
