Global Parts 2759C Radiator

Overview of Global Parts Radiator for Hyundai Santa Fe

The Global Parts radiator part number 2759C is designed specifically for Hyundai Santa Fe models, providing reliable cooling performance. This radiator features a durable aluminum core and plastic tanks, engineered to maintain optimal engine temperature and support transmission oil cooling.

• Core dimensions: 15.75 inches height, 28.27 inches width, 1.02 inches thickness
• Constructed with a single-row aluminum core for efficient heat dissipation
• Includes a transmission oil cooler with tube fittings and 17.38 inches distance between fittings
• Down flow design for effective coolant circulation
• Core fin density of 68 fins per 4 inches enhances cooling capacity
• Plastic tank material for corrosion resistance and weight reduction
• Inlet diameter of 1.38 inches supports proper coolant flow

Detailed Radiator Specifications and Features

This Global Parts radiator (part number 2759C) is engineered with a 400.05 mm (15.75 inch) core height and 718.06 mm (28.27 inch) core width, providing a substantial surface area for heat exchange. The 25.91 mm (1.02 inch) core thickness and single-row design optimize coolant flow and heat dissipation. The aluminum core material offers durability and efficient thermal conductivity, while the plastic tanks reduce weight and resist corrosion. The radiator also includes a transmission oil cooler with tube fittings spaced 17.38 inches apart, featuring a 0.31 inch fitting diameter to support transmission fluid cooling. The down flow configuration ensures effective coolant movement through the radiator, and the 68 fins per 4 inches increase the surface area for heat transfer.

Compatible Vehicles and Applications

This radiator is compatible with Hyundai Santa Fe models requiring part number 2759C. It is designed to replace original equipment radiators and supports vehicles equipped with transmission oil coolers but without engine oil coolers. This part is suitable for addressing cooling system issues related to overheating and transmission fluid temperature regulation.

• Overheating engine due to radiator core damage or clogging
• Transmission fluid overheating caused by faulty or missing transmission oil cooler
• Coolant leaks from cracked or worn plastic tanks
• Reduced cooling efficiency from bent or damaged fins
• Corrosion-related radiator failure in aluminum cores

Installation Notes and Tips

When installing the Global Parts radiator 2759C on a Hyundai Santa Fe, ensure all hose connections and fittings are properly secured to prevent leaks. Verify the transmission oil cooler fittings align with the vehicle’s transmission lines. It is recommended to flush the cooling system before installation to remove debris and contaminants. Use manufacturer-specified coolant and follow torque specifications for mounting bolts. Inspect and replace any worn hoses or clamps during installation for optimal performance.

Quality Assurance and Warranty Information

Global Parts radiators are manufactured to meet or exceed OEM standards for fit, form, and function. The aluminum core and plastic tank construction provide durability and corrosion resistance. This radiator includes a transmission oil cooler to support transmission temperature management. Warranty coverage details should be confirmed with the distributor or retailer, as terms may vary.
