Global Parts 9412143 A/C Receiver Drier Kit

Global Parts System Service Kit for Rear A/C

Global Parts Part Number 9412143 is a System Service Kit for rear air conditioning applications on select Chevrolet and GMC vans. It combines the core service components needed for a proper A/C refresh in one application-specific kit.

The Global Parts System Service Kit line is built around matched HVAC service parts for vehicles that use an accumulator/receiver drier setup, expansion devices, and sealing components. For rear A/C service on the listed Chevrolet Express, Chevrolet G-series, GMC Savana, and GMC G-series models, this kit supports a more complete repair path.

• Part number 9412143
• System Service Kit for HVAC A/C accumulator/receiver drier applications
• Includes components referenced by the manufacturer as an accumulator/receiver drier/desiccant bag, expansion device/orifice tube, rear expansion device when equipped, and O-ring rapid seal kit unless otherwise noted
• Compatible with rear A/C configurations on select Chevrolet and GMC vans
• Application-specific fitment for 1993-1996 models

Compatible Vehicle Applications

• Fits 1996 Chevrolet Express 1500, N/A, w/ Rear AC; Hoses on Rear
• Fits 1996 Chevrolet Express 2500, N/A, w/ Rear AC; Hoses on Rear
• Fits 1996 Chevrolet Express 3500, N/A, w/ Rear AC; Hoses on Rear
• Fits 1996 Chevrolet G30, N/A, w/ Rear AC; Hoses on Rear
• Fits 1996 GMC G3500, N/A, w/ Rear AC; Hoses on Rear
• Fits 1996 GMC Savana 1500, N/A, w/ Rear AC; Hoses on Rear
• Fits 1996 GMC Savana 2500, N/A, w/ Rear AC; Hoses on Rear
• Fits 1996 GMC Savana 3500, N/A, w/ Rear AC; Hoses on Rear
• Fits 1993-1995 Chevrolet G10, N/A, w/ Rear AC
• Fits 1993-1995 Chevrolet G20, N/A, w/ Rear AC
• Fits 1993-1995 Chevrolet G30, N/A, w/ Rear AC
• Fits 1993-1995 GMC G1500, N/A, w/ Rear AC
• Fits 1993-1995 GMC G2500, N/A, w/ Rear AC
• Fits 1993-1995 GMC G3500, N/A, w/ Rear AC
• Fits 1993 Chevrolet G10, N/A, w/ Rear AC; Factory R134
• Fits 1993 Chevrolet G20, N/A, w/ Rear AC; Factory R134
• Fits 1993 Chevrolet G30, N/A, w/ Rear AC; Factory R134
• Fits 1993 GMC G1500, N/A, w/ Rear AC; Factory R134
• Fits 1993 GMC G2500, N/A, w/ Rear AC; Factory R134
• Fits 1993 GMC G3500, N/A, w/ Rear AC; Factory R134

What This Kit Helps Address

• Loss of A/C cooling performance after component replacement
• Moisture contamination in the refrigerant circuit
• Restricted or worn expansion device operation
• Seal leakage at service points and connections
• Rear A/C system service on vans with rear-mounted HVAC plumbing

Installation Notes

Verify the vehicle’s rear A/C configuration and hose routing before ordering. This kit is listed for specific Chevrolet Express, Chevrolet G-series, GMC Savana, and GMC G-series applications, including 1993 factory R134 vehicles and 1996 vans with rear A/C and rear hoses. Replace system components according to the vehicle’s service procedure and evacuate, leak-check, and recharge the system after repair.

Quality Assurance

Global Parts System Service Kits are assembled as application-based HVAC service solutions for the listed vehicles. Part Number 9412143 is cataloged for direct use on the confirmed Chevrolet and GMC fitments shown above.
