GSP 116000 Wheel Bearing and Hub Assembly - Front
| Brand | GSP 116000 |
|---|---|
| Position | Front |
| Wheel Stud Quantity | 3 |
| Hub Pilot Diameter | 63.8 |
| Flange Offset | 51.1 |
| Flange Diameter | 144.5 |
| Bolt Circle Diameter | 114.3 |
| Anti Lock Braking System | N |
| Bearing Generation | Gen 3 |
| Bearing Type | Ball |
| Bolts Included | Yes |
| Inside Spline Quantity | 26 |
| Pilot Diameter | 63.8 |
| Product line | GSP New Wheel Bearing and Hub Assembly |
| Fits | Ford · 39 vehicles |
OE-style replacement. New wheel bearing and hub assembly for direct service replacement.
Gen 3 design. Ball bearing construction with a 26-spline internal interface.
Dimension-matched fit. Includes 114.3 mm bolt circle and 63.8 mm hub pilot diameter.
Cross-references Centric Parts 400.65001E, MOOG Hub Assemblies 515000 and 730-0073 for the same application. See all 5.
Will it fit your vehicle?
Free return shipping if it doesn't fit.
Wheel Bearing and Hub Assembly Overview
This GSP New Wheel Bearing and Hub Assembly is built for direct replacement service on the front of the vehicle. It is a fit for 1990-1997 Ford Aerostar, front, and uses a Gen 3 ball bearing design with a 26-spline internal interface.
Part number 116000 is identified for this application and cross-references Centric Parts 400.65001E for the same use. The hub assembly includes a 114.3 mm bolt circle, 63.8 mm hub pilot diameter, and 144.5 mm flange diameter for proper wheel and hub interface.
Key Features
- Gen 3 wheel bearing and hub assembly construction
- Ball bearing type for hub service applications
- 3 wheel studs with bolts included
- 114.3 mm bolt circle diameter
- 63.8 mm hub pilot diameter and 144.5 mm flange diameter
- 26 inside spline count
Fitment Details
Fits 1990-1997 Ford Aerostar, front.
Use part number 116000 when matching the correct hub assembly for this Ford Aerostar application. The same part number, 116000, is also referenced for cross-checking against related hub assembly listings.
Common Issues This Part Can Address
- Wheel end noise from a worn hub bearing
- Excessive play at the wheel hub
- Improper wheel mounting due to hub wear
- ABS-related fitment mismatch is avoided here because this unit is listed without ABS
Installation Notes and Tips
Confirm the front position, bolt circle, spline count, and pilot diameter before installation. Verify that the vehicle uses the same non-ABS configuration shown in the fitment data. Match the hub dimensions to the existing assembly to ensure correct wheel and axle interface.
Quality Assurance
GSP New Wheel Bearing and Hub Assembly products are cataloged as new replacement components for driveline and axle service. Review the listed dimensions and fitment details carefully before ordering.
| Year | Make | Model | Submodel | Drive Type | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|---|---|
| 1997 | Ford | Aerostar | XLT Plus | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1997 | Ford | Aerostar | Base | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1997 | Ford | Aerostar | XLT | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1996 | Ford | Aerostar | XLT Plus | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1996 | Ford | Aerostar | Base | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1996 | Ford | Aerostar | XLT | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1995 | Ford | Aerostar | XLT Plus | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1995 | Ford | Aerostar | Base | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1995 | Ford | Aerostar | XLT | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1994 | Ford | Aerostar | Eddie Bauer | AWD | — | — | Front | GSP New Wheel Bearing and Hub Assembly |
| 1994 | Ford | Aerostar | XL Plus | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1994 | Ford | Aerostar | XL | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1994 | Ford | Aerostar | XLT Plus | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1994 | Ford | Aerostar | XLT | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1994 | Ford | Aerostar | Base | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1993 | Ford | Aerostar | Eddie Bauer | AWD | — | — | Front | GSP New Wheel Bearing and Hub Assembly |
| 1993 | Ford | Aerostar | XL Plus | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1993 | Ford | Aerostar | XL | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1993 | Ford | Aerostar | XLT Plus | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1993 | Ford | Aerostar | XLT | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1993 | Ford | Aerostar | Base | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1992 | Ford | Aerostar | Eddie Bauer | AWD | — | — | Front | GSP New Wheel Bearing and Hub Assembly |
| 1992 | Ford | Aerostar | XL Plus | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1992 | Ford | Aerostar | XL | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1992 | Ford | Aerostar | XLT Plus | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1992 | Ford | Aerostar | Base | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1992 | Ford | Aerostar | XLT | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1991 | Ford | Aerostar | XL Plus | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1991 | Ford | Aerostar | Eddie Bauer | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1991 | Ford | Aerostar | XL | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1991 | Ford | Aerostar | XLT Plus | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1991 | Ford | Aerostar | Base | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1991 | Ford | Aerostar | XLT | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1990 | Ford | Aerostar | XL Plus | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1990 | Ford | Aerostar | Eddie Bauer | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1990 | Ford | Aerostar | XL | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1990 | Ford | Aerostar | XLT Plus | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1990 | Ford | Aerostar | Base | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 1990 | Ford | Aerostar | XLT | AWD | 4.0L | V6 | Front | GSP New Wheel Bearing and Hub Assembly |
