Will it fit your vehicle?
Confirm before you buy. Free return shipping if it doesn't fit.
GSP 126061 Wheel Bearing and Hub Assembly - Front
| Brand | GSP 126061 |
|---|---|
| Position | Front |
| Wheel Stud Quantity | 4 |
| Hub Pilot Diameter | 120.95 |
| Flange Offset | 54.3 |
| Flange Diameter | 205 |
| Bolt Circle Diameter | 165 |
| Anti Lock Braking System | N |
| Bearing Generation | Gen 3 |
| Bearing Type | Taper |
| Bolts Included | Yes |
| Inside Spline Quantity | 33 |
| Pilot Diameter | 120.95 |
| Product line | GSP New Wheel Bearing and Hub Assembly |
| Fits | Dodge · 28 vehicles |
OE-style replacement. New wheel bearing and hub assembly for direct service replacement.
Gen 3 bearing design. Taper bearing construction with a 33-spline hub interface.
Complete hub geometry. Includes 4 studs, 165 mm bolt circle, and bolts included.
Cross-references Centric Parts 402.67010E, GMB 799-0168 and MOOG Hub Assemblies 515061 for the same application. See all 6.
Will it fit your vehicle?
Free return shipping if it doesn't fit.
Wheel Bearing and Hub Assembly Overview
This GSP wheel bearing and hub assembly is built for front-end service on select heavy-duty Ram applications. It is identified by part number 126061 and matches the hub dimensions and spline count needed for the listed fitments.
Key Features
- Gen 3 taper bearing construction for hub service applications.
- 4 wheel studs with a 165 mm bolt circle diameter.
- 33 inside splines and a 120.95 mm hub pilot diameter.
- Bolts included for a more complete replacement assembly.
- ABS not equipped configuration.
Detailed Description
GSP 126061 is a new wheel bearing and hub assembly for front installation on 2003 and 2005 Dodge Ram 2500 and Dodge Ram 3500 models. The assembly uses a taper bearing design and Gen 3 bearing generation, with a 205 mm flange diameter, 54.3 mm flange offset, and 120.95 mm pilot diameter. For buyers searching for a Dodge Ram 2500 front wheel bearing and hub assembly or a Dodge Ram 3500 front hub assembly, this part number 126061 provides the specified hub geometry and spline count for the listed applications.
This part cross-references MOOG Hub Assemblies (e.g., 515061) for the same application.
Common Issues This Part Can Address
- Wheel bearing noise from a worn front hub assembly.
- Excessive play or looseness at the wheel end.
- Hub damage affecting wheel mounting and rotation.
- Incorrect spline or bolt pattern match on the replacement hub.
Installation Notes and Quality Assurance
Verify the 33-spline count, 4-stud pattern, 165 mm bolt circle, and ABS configuration before installation. Confirm fitment against the vehicle application and compare the original hub dimensions to part number 126061. GSP New Wheel Bearing and Hub Assembly is the product line designation for this replacement hub assembly.
| Year | Make | Model | Submodel | Drive Type | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|---|---|
| 2005 | Dodge | Ram 2500 | Laramie | — | 5.9L | L6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2005 | Dodge | Ram 2500 | Laramie | 4WD | 5.7L | V8 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2005 | Dodge | Ram 2500 | ST | 4WD | 5.7L | V8 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2005 | Dodge | Ram 2500 | SLT | 4WD | 5.7L | V8 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2005 | Dodge | Ram 3500 | Laramie | 4WD | 5.9L | L6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2005 | Dodge | Ram 3500 | SLT | 4WD | 5.9L | L6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2005 | Dodge | Ram 3500 | ST | 4WD | 5.9L | L6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2005 | Dodge | Ram 3500 | SLT | 4WD | 5.7L | V8 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2005 | Dodge | Ram 3500 | ST | 4WD | 5.7L | V8 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2005 | Dodge | Ram 3500 | Laramie | 4WD | 5.7L | V8 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2003 | Dodge | Ram 2500 | Laramie | 4WD | 8.0L | V10 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2003 | Dodge | Ram 2500 | SLT | 4WD | 8.0L | V10 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2003 | Dodge | Ram 2500 | Laramie | 4WD | 5.7L | V8 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2003 | Dodge | Ram 2500 | ST | 4WD | 8.0L | V10 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2003 | Dodge | Ram 2500 | Laramie | 4WD | 5.9L | L6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2003 | Dodge | Ram 2500 | ST | 4WD | 5.7L | V8 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2003 | Dodge | Ram 2500 | SLT | 4WD | 5.7L | V8 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2003 | Dodge | Ram 2500 | ST | 4WD | 5.9L | L6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2003 | Dodge | Ram 2500 | SLT | 4WD | 5.9L | L6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2003 | Dodge | Ram 3500 | Laramie | 4WD | 8.0L | V10 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2003 | Dodge | Ram 3500 | SLT | 4WD | 8.0L | V10 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2003 | Dodge | Ram 3500 | ST | 4WD | 8.0L | V10 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2003 | Dodge | Ram 3500 | SLT | 4WD | 5.7L | V8 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2003 | Dodge | Ram 3500 | ST | 4WD | 5.7L | V8 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2003 | Dodge | Ram 3500 | Laramie | 4WD | 5.7L | V8 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2003 | Dodge | Ram 3500 | Laramie | 4WD | 5.9L | L6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2003 | Dodge | Ram 3500 | ST | 4WD | 5.9L | L6 | Front | GSP New Wheel Bearing and Hub Assembly |
| 2003 | Dodge | Ram 3500 | SLT | 4WD | 5.9L | L6 | Front | GSP New Wheel Bearing and Hub Assembly |
| No rows match your filter. | ||||||||
