Hella 965400071 A/C Clutch Relay

Hella A/C Clutch Relay for HVAC Control

The Hella 965400071 is a 12V A/C clutch relay built for HVAC relay circuits that need reliable switching performance. With a 4-pin, normally open contact design and a 40A rated current, it supports the electrical demands found in a wide range of Ford, Hyundai, Subaru, Mercedes-Benz, Toyota, and other applications.

• 12V relay with 4-pole design and normally open contact
• 40A rated current and 40A capacity at 12V
• Supports ohmic loads up to 30A, inductive loads up to 15A, and capacitive loads up to 5A
• Black housing with holder and Plug Type A
• IP54 protection rating for added resistance to dust and moisture exposure
• Operating temperature range from -40°C to 125°C
• Wiring diagram S1 for straightforward circuit identification

Detailed Product Overview

Hella part number 965400071 is designed for HVAC relay service where the A/C clutch circuit requires a 12V, normally open switching relay. The relay’s 4-pin configuration, Plug Type A interface, and S1 wiring diagram make it a direct-fit style electrical component for many late-model and older vehicles. It is listed across a broad range of applications, including 2022-2024 Hyundai Ioniq 5, 2014-2023 Ford Transit Connect, and 2005-2023 Subaru Outback, along with many other Ford, Hyundai, Kia, Land Rover, Mercedes-Benz, Mitsubishi, Mazda, Toyota, Lexus, and Chevrolet platforms.

This part cross-references 611 004 and 867513 for the same application.

Common HVAC Issues This Relay Can Address

• A/C clutch not engaging when the HVAC system calls for compressor operation
• Intermittent compressor cycling caused by relay contact wear
• Electrical switching problems in the A/C control circuit
• Relay failure related to heat, vibration, or moisture exposure
• HVAC system faults traced to a worn or incorrect relay specification

Installation Notes and Fitment Tips

Verify the vehicle’s relay cavity, connector style, and wiring diagram before installation. This relay uses a 4-pin connector with Plug Type A and S1 wiring, so matching the original layout is important for proper A/C clutch operation. Confirm the application by year, make, and model before replacing the relay in the HVAC relay block.

• Fits 2022-2024 Hyundai Ioniq 5, N/A
• Fits 2023-2024 Hyundai Palisade, N/A
• Fits 2022-2024 Hyundai Santa Cruz, N/A
• Fits 2016-2024 Hyundai Santa Fe, N/A
• Fits 2006-2012 Hyundai Santa Fe, N/A
• Fits 2005-2024 Hyundai Tucson, N/A
• Fits 2014-2023 Ford Transit Connect, N/A
• Fits 2018-2023 Hyundai Kona, N/A
• Fits 2019-2023 Hyundai Nexo, N/A
• Fits 2020-2023 Hyundai Venue, N/A
• Fits 2015-2023 Land Rover Discovery Sport, N/A
• Fits 2014-2023 Land Rover Range Rover Sport, N/A
• Fits 2018-2023 Land Rover Range Rover Velar, N/A
• Fits 2003-2023 Mitsubishi Outlander, N/A
• Fits 2019-2023 Subaru Ascent, N/A
• Fits 1998-2023 Subaru Forester, N/A
• Fits 2005-2023 Subaru Outback, N/A
• Fits 2012-2023 Subaru WRX, N/A

Quality Assurance

Hella is a recognized automotive electrical brand, and this relay is specified with clear electrical ratings, temperature limits, and protection details to support accurate replacement selection. Part number 965400071 is built to meet the demands of HVAC relay service in vehicles such as the Hyundai Tucson, Ford Transit Connect, and Subaru Outback.
