InMotion WA512212 Wheel Bearing and Hub Assembly - Rear

Rear Wheel Bearing Hub Assembly for Toyota RAV4

InMotion WA512212 is a rear wheel bearing and hub assembly for the 1996-2005 Toyota RAV4, Standard Grade. It is built from OE data and measurements for direct replacement fitment, with a precision-machined design that supports proper wheel mounting, braking alignment, and long service life.

• Fits 1996-2005 Toyota RAV4, rear, Standard Grade
• Part number: WA512212
• 5 wheel studs with 4 flange bolt holes
• ABS sensor included
• Wheel pilot diameter: 60.0 mm
• Brake pilot diameter: 62.0 mm
• Hub pilot diameter: 84.0 mm
• Bolt circle diameter: 114.3 mm / 4.5 in
• Flange diameter: 152.0 mm
• Flange offset: 69.0 mm
• Offset trapezoid flange shape

Product Details

WA512212 is engineered as a direct replacement wheel hub assembly for the rear of the Toyota RAV4. The assembly is manufactured with strict quality-control criteria and built to match the designated application using OE specifications, helping ensure correct fitment and consistent wheel bearing performance. The integrated ABS sensor supports vehicles equipped with anti-lock braking systems, while the hub and flange dimensions are matched to the original mounting geometry.

This part cross-references Monroe Shocks & Struts (e.g., 172286, 182286) for the same application.

What This Part Helps Address

• Rear wheel bearing noise or rough rotation
• Excessive wheel play or looseness at the hub
• ABS warning light concerns related to the rear hub sensor
• Improper wheel mounting caused by worn hub components
• Brake and wheel alignment issues tied to hub wear

Installation Notes

Fits 1996-2005 Toyota RAV4, rear. Confirm the flange bolt pattern, bolt circle diameter, and pilot dimensions before installation. Inspect the mating surfaces, axle area, and brake components for wear or damage, and verify ABS connector routing and sensor alignment during replacement. Use the vehicle service procedure and torque specifications for final assembly.

Quality Assurance

InMotion manufactures this hub assembly using OE data, precise measurements, and controlled production standards to support accurate fitment and dependable operation on the Toyota RAV4 rear axle application.
