InMotion WA512267 Wheel Bearing and Hub Assembly - Rear

Rear Wheel Bearing Hub Assembly for Kia and Hyundai

InMotion WA512267 is a rear wheel bearing and hub assembly built for specific Kia Sportage and Hyundai Tucson applications. It is engineered from OE data and measurements for direct replacement fitment, with the hub, bearing, and ABS sensor integration matched to the original design.

• Rear wheel bearing and hub assembly for select 2005-2010 Kia Sportage and 2005, 2009 Hyundai Tucson models
• Part number WA512267 for accurate ordering and fitment verification
• 5 wheel studs with a 114.3 bolt circle diameter
• ABS sensor included for vehicles equipped with wheel speed sensing at the hub
• Wheel pilot diameter: 67.0 mm
• Brake pilot diameter: 76.0 mm
• Hub pilot diameter: 76.5 mm
• Flange diameter: 139.0 mm with 53.5 flange offset

Fitment Details

Compatible with rear applications on 2005-2010 Kia Sportage and rear applications on 2005 and 2009 Hyundai Tucson. This WA512267 hub assembly is built for the listed standard grade rear positions and is intended to match the original mounting and sensor layout.

This part cross-references Monroe Shocks & Struts (e.g., 172286, 182286) for the same application.

What This Hub Assembly Helps Address

• Wheel bearing noise from a worn rear hub assembly
• ABS warning light concerns related to a failed hub-mounted sensor
• Excessive wheel play or looseness at the rear hub
• Uneven hub rotation or rough bearing feel
• Fitment issues when replacing a damaged OE-style rear hub

Installation Notes and Tips

Verify the rear position, stud count, and bolt circle diameter before installation. Confirm the hub pilot and brake pilot dimensions against the original part, and inspect the mating surfaces, axle area, and ABS connector condition during replacement. For best results, compare the removed unit to WA512267 before final assembly.

Quality Assurance

InMotion manufactures this wheel bearing and hub assembly using high-precision processes and strict quality-control standards. Each unit is engineered from OE data and measurements to support proper fitment, performance, and service life in the listed Kia Sportage and Hyundai Tucson rear applications.
