InMotion WA512514 Wheel Bearing and Hub Assembly - Rear

Rear Wheel Bearing Hub Assembly

InMotion WA512514 is a rear wheel bearing and hub assembly built for direct replacement on select Jeep and Chrysler applications. It is engineered from OE data and measurements to match the original fit, with precision manufacturing and quality control focused on fitment, performance, and service life.

Compatible with 2014-2022 Jeep Cherokee rear and 2015-2017 Chrysler 200 rear, this hub assembly includes an integrated ABS sensor for vehicles that require wheel speed signal integration. The WA512514 is designed around the specified flange, pilot, and bolt pattern dimensions for accurate installation and dependable wheel support.

Key Features

• Rear wheel bearing and hub assembly for OE-style replacement
• Integrated anti-lock brake sensor included
• 5 wheel studs with 4 flange bolt holes
• Flange diameter: 130.2 mm; flange offset: 48.6 mm
• Bolt circle diameter: 110.0 mm / 4.33 in.
• Wheel pilot diameter: 65.0 mm
• Brake pilot diameter: 69.9 mm
• Hub pilot diameter: 91.9 mm
• Rectangle flange shape

Detailed Description

InMotion WA512514 is manufactured as a direct-fit rear hub assembly for vehicles that use the listed OE dimensions and sensor configuration. The part number WA512514 is built to align with the original hub mounting geometry, wheel pilot, brake pilot, and stud layout, helping maintain proper wheel location and brake component fit. This makes it a practical replacement for a worn rear hub on a Jeep Cherokee or Chrysler 200 when the original assembly shows bearing noise, looseness, or ABS-related concerns.

This part cross-references Monroe Shocks & Struts (e.g., 172286, 182286) for the same application.

Vehicle Fitment

• Fits 2014-2022 Jeep Cherokee, rear, Standard Grade
• Fits 2015-2017 Chrysler 200, rear, Standard Grade

Common Issues This Part Can Address

• Rear wheel bearing noise or humming
• Wheel play or looseness at the hub
• ABS warning light caused by a failing wheel speed sensor circuit
• Uneven hub wear from a damaged or worn original assembly
• Improper wheel mounting due to hub or stud wear

Installation Notes and Tips

Verify rear fitment by year, make, model, and position before installation. Confirm the bolt circle, pilot diameters, flange offset, and ABS sensor configuration match the original part on the vehicle. Clean the mounting surface thoroughly and inspect related brake and suspension components for wear before installing the new hub assembly.

Quality Assurance

InMotion manufactures this hub assembly using high-precision processes and strict quality-control criteria. Each unit is engineered from OE data and measurements to support correct fitment and consistent performance in the specified Jeep Cherokee and Chrysler 200 rear applications.
