InMotion WA512523 Wheel Bearing and Hub Assembly - Rear

Rear Wheel Hub Assembly for Mazda 3

InMotion WA512523 is a rear wheel bearing and hub assembly engineered for 2014-2018 Mazda 3 and Mazda 3 Sport Standard Grade applications. Built from OE data and measurements, it is made for direct replacement use where precise fitment, stable wheel support, and consistent sensor performance matter.

Key Features

• Direct replacement rear hub assembly for Mazda 3 and Mazda 3 Sport
• Engineered from OE data and dimensional measurements
• High-precision manufacturing with strict quality-control criteria
• Integrated ABS wheel speed sensor included
• 5 wheel studs with 4 flange bolt holes
• Flange diameter: 138.7 mm; flange offset: 56.9 mm
• Wheel pilot diameter: 66.9 mm; brake pilot diameter: 67.9 mm; hub pilot diameter: 82.8 mm
• Bolt circle diameter: 114.3 mm / 4.5 in
• Rectangle flange shape for designated rear applications

Detailed Description

InMotion WA512523 is a rear wheel bearing and hub assembly designed for 2014-2018 Mazda 3 and 2014-2018 Mazda 3 Sport models in Standard Grade trim. The assembly is manufactured to match OE dimensions and application-specific measurements, helping ensure proper wheel mounting, bearing support, and ABS sensor integration. For buyers searching for a rear wheel hub assembly for Mazda 3, WA512523 provides a direct replacement option built around the original fitment requirements.

This part number, WA512523, is specified for rear position use and is built with a 5-stud, 4-bolt-hole flange layout, 114.3 mm bolt circle, and the listed pilot and flange dimensions. It is a practical choice when replacing a worn rear hub on a Mazda 3 or Mazda 3 Sport and when maintaining factory-style wheel and sensor geometry is important.

What It Helps Address

• Wheel bearing noise from a worn rear hub assembly
• ABS warning light concerns related to hub-mounted sensor function
• Wheel looseness or play caused by hub wear
• Uneven wheel mounting from damaged flange or pilot surfaces
• Vibration or roughness traced to rear hub deterioration

Installation Notes and Tips

Confirm rear-position fitment before installation and verify the vehicle is a 2014-2018 Mazda 3 or Mazda 3 Sport Standard Grade application. Compare the flange, pilot, stud, and bolt-circle dimensions to the removed part before pressing or bolting the assembly into place. Because the ABS sensor is included, inspect the connector routing and tone/sensor interface during installation to help avoid warning lights after service.

Quality Assurance

InMotion manufactures this hub assembly using high-precision processes and strict quality-control criteria. Each WA512523 unit is engineered from OE data and measurements to support proper fitment, performance, and service life in the designated rear applications.
