InMotion WA513200 Wheel Bearing and Hub Assembly - Front

Front Wheel Bearing Hub Assembly for Blazer and Jimmy

InMotion WA513200 is a front wheel bearing and hub assembly built for direct replacement on select Chevrolet Blazer and GMC Jimmy applications. It is engineered from OE data and measurements to support proper fitment, wheel mounting, and long service life.

This assembly includes an integrated ABS sensor and is manufactured with high-precision processes and strict quality-control standards. For drivers searching for a front wheel hub assembly for 1998-2005 Chevrolet Blazer or 1998-2004 GMC Jimmy, WA513200 provides the correct application-specific design.

Key Features

• Part number: WA513200
• Front wheel bearing and hub assembly
• Integrated anti-lock brake sensor included
• 5 wheel studs
• 3 flange bolt holes
• Modified flange shape
• Flange diameter: 146.0 mm
• Flange offset: 47.0 mm
• Wheel pilot diameter: 70.1 mm
• Brake pilot diameter: 70.5 mm
• Hub pilot diameter: 88.9 mm
• Bolt circle diameter: 120.8 mm / 4.75 in

Detailed Description

InMotion WA513200 is a wheel bearing and hub assembly designed as a direct replacement for the original front hub on compatible Chevrolet Blazer and GMC Jimmy vehicles. The assembly is built using OE reference data to match the required dimensions, stud pattern, pilot diameters, and flange geometry for the listed applications. That makes it a practical choice when replacing a worn front hub on a 1998-2005 Chevrolet Blazer or a 1998-2004 GMC Jimmy. The part number WA513200 is also a useful reference when comparing replacement options for the same front axle position.

This hub assembly is built with a 5-stud wheel mounting pattern, ABS sensor provision, and the specified flange and pilot measurements needed for proper wheel and brake interface. This part cross-references Monroe Shocks & Struts (e.g., 172286, 182286) for the same application.

What It Helps Fix

• Front wheel bearing noise or rough rotation
• Excessive play in the front hub assembly
• ABS warning light concerns related to the hub sensor
• Wheel mounting issues caused by worn hub components
• Vibration or looseness from a deteriorated front wheel hub

Installation Notes and Tips

• Fits 1998-2005 Chevrolet Blazer, front.
• Fits 1998-2004 GMC Jimmy, front.
• Confirm flange, pilot, and bolt-circle measurements before installation.
• Inspect the mating surfaces, axle hardware, and brake components for wear before assembly.
• Verify ABS connector routing and sensor alignment during installation.

Quality Assurance

InMotion manufactures this hub assembly with precision processes and strict quality-control criteria. Each unit is engineered to match the designated application using OE data and measurements for fitment, performance, and durability.
