InMotion WA513250 Wheel Bearing and Hub Assembly - Front

Front Wheel Bearing and Hub Assembly for Suzuki Verona

InMotion WA513250 is a front wheel bearing and hub assembly built for 2004-2006 Suzuki Verona models. It is engineered from OE data and measurements for direct replacement fitment, with the hub, bearing, and ABS sensor integration needed for a precise front-end repair.

• Fits 2004-2006 Suzuki Verona, front
• 28-spline hub design
• 4 wheel studs with a 4.5 in. bolt circle diameter
• 3 flange bolt holes with a modified flange shape
• ABS sensor included
• Wheel pilot diameter: 56.3 mm
• Brake pilot diameter: 60.0 mm
• Hub pilot diameter: 91.2 mm
• Flange diameter: 139.0 mm
• Flange offset: 37.0 mm

OE-Style Fitment and Construction

This InMotion wheel bearing and hub assembly is manufactured with high-precision processes and strict quality-control standards. The WA513250 is designed for the front position on the Suzuki Verona and follows OE measurements to support proper wheel mounting, brake alignment, and sensor function. If you are replacing a worn front hub on a 2004, 2005, or 2006 Suzuki Verona, this part number WA513250 provides the correct application-specific dimensions for a direct replacement.

Common Problems This Part Can Address

• Front wheel noise caused by a worn bearing
• ABS warning light from a failed hub sensor assembly
• Wheel looseness or play at the front hub
• Uneven wheel mounting from damaged hub pilot surfaces
• Vibration or rough rotation from hub wear

Installation Notes

Verify the vehicle year, make, model, and front position before installation. Confirm the 28-spline configuration, 4-stud wheel pattern, and ABS sensor connection match the original assembly on the vehicle. Inspect the knuckle, axle interface, and mounting surfaces for wear or damage before installing WA513250. This part cross-references Monroe Shocks & Struts (e.g., 172286, 182286) for the same application.

Quality Assurance

InMotion manufactures this hub assembly using OE data, precise measurements, and controlled production standards to support fitment, performance, and service life. Part number WA513250 is built as a direct replacement for the original front hub assembly on the Suzuki Verona.
