InMotion WA513278 Wheel Bearing and Hub Assembly - Front

Front Wheel Bearing and Hub Assembly for Hyundai

The InMotion WA513278 is a front wheel bearing and hub assembly built for direct replacement on select Hyundai applications. It is engineered from OE data and measurements for fitment, performance, and service life, with an integrated ABS sensor included.

Key Features

• Front wheel bearing and hub assembly for select Hyundai Genesis and Hyundai Equus models
• Direct replacement design based on OE dimensions
• Integrated anti-lock brake sensor included
• 5 wheel studs with 4 flange bolt holes
• Wheel pilot diameter: 67.0 mm
• Brake pilot diameter: 69.0 mm
• Hub pilot diameter: 80.0 mm
• Bolt circle diameter: 114.3 mm
• Flange diameter: 139.0 mm with 53.4 mm flange offset

Detailed Description

InMotion WA513278 is a front hub assembly designed for Hyundai Genesis and Hyundai Equus vehicles with standard grade fitment. It is manufactured with precision processes and strict quality-control criteria to match the original part’s critical dimensions. This front wheel bearing and hub assembly supports proper wheel mounting, hub alignment, and ABS system operation on 2009-2014 Hyundai Genesis and 2011-2016 Hyundai Equus models.

This part cross-references Monroe Shocks & Struts (e.g., 172286, 182286) for the same application.

What This Part Helps Address

• Wheel bearing noise from a worn front hub assembly
• ABS warning light concerns related to a failed hub sensor
• Wheel looseness or play at the front axle
• Improper wheel mounting caused by hub wear
• Vibration or uneven rotation from a damaged bearing surface

Installation Notes and Tips

Fits 2009-2014 Hyundai Genesis, front. Fits 2011-2016 Hyundai Equus, front. Confirm bolt circle, pilot diameters, and ABS sensor connection before installation. Clean the mounting surface and inspect related suspension and brake components during replacement to help ensure proper seating and operation. Use the vehicle service procedure and torque specifications for the final installation.

Quality Assurance

InMotion manufactures this hub assembly using OE data, precise measurements, and controlled production standards to support correct fitment and consistent performance on the listed Hyundai applications.
