InMotion WA513328 Wheel Bearing and Hub Assembly - Front

Volvo Front Wheel Hub Assembly

InMotion WA513328 is a front wheel bearing and hub assembly built for select Volvo applications. It is engineered from OE data and measurements for direct replacement fitment, with precision manufacturing and quality control focused on fit, performance, and service life.

Compatible with 2007-2018 Volvo S60, V60, V60 Cross Country, S60 Cross Country, XC60, S80, XC70, and V70 front applications, this hub assembly includes the ABS sensor and is built around the original mounting and pilot dimensions.

Key Features

• Part number: WA513328
• Front wheel bearing and hub assembly for Volvo driveline and axle service
• OE-data-based design for direct replacement fitment
• ABS sensor included
• 40-spline configuration
• 5-wheel-stud hub pattern
• Wheel pilot diameter: 63.2 mm
• Brake pilot diameter: 63.4 mm
• Hub pilot diameter: 82.0 mm
• Flange diameter: 136.3 mm
• Flange offset: 67.8 mm
• Bolt circle diameter: 108.2 mm

Detailed Description

InMotion WA513328 is a front wheel bearing and hub assembly designed for Volvo S60, Volvo V60, Volvo XC60, Volvo S80, Volvo XC70, Volvo V70, and related Cross Country models listed below. The assembly is manufactured to match OE measurements, including spline count, pilot diameters, flange dimensions, and bolt circle specification, helping maintain proper wheel mounting and sensor integration. This part cross-references Monroe Shocks & Struts (e.g., 172286, 182286) for the same application.

What It Helps Address

• Front wheel bearing noise or rough rotation
• Wheel looseness caused by hub wear
• ABS warning light concerns related to hub-mounted sensor failure
• Improper wheel mounting from worn pilot surfaces
• Vibration or play from a deteriorated hub assembly

Installation Notes

Verify the vehicle’s front application, spline count, and pilot dimensions before installation. Confirm ABS connector routing and sensor alignment during service, and inspect related suspension and brake components for wear while the hub is removed. For Volvo S60, V60, XC60, S80, XC70, and V70 front hub replacement, match the part number and fitment details to the vehicle build before final assembly.

Quality Assurance

InMotion manufactures this hub assembly using high-precision processes and strict quality-control criteria. Each unit is engineered from OE data and measurements to support correct fitment, performance, and longevity for the listed Volvo front applications.
