InMotion WA515128 Wheel Bearing and Hub Assembly - Front

Front Wheel Hub Assembly for Hummer H3 and H3T

InMotion WA515128 is a front wheel bearing and hub assembly built for 2009-2010 Hummer H3 and 2009-2010 Hummer H3T applications. It is engineered from OE data and measurements for direct replacement fitment, with the hub, bearing, and ABS sensor integration matched to the original design.

• Fits 2009-2010 Hummer H3, front
• Fits 2009-2010 Hummer H3T, front
• 33-spline hub design
• 6 wheel studs with 3 flange bolt holes
• ABS sensor included
• Triangle flange shape with 178.5 flange diameter
• Wheel pilot diameter: 100.0; hub pilot diameter: 99.3
• Brake pilot diameter: 100.7; flange offset: 49.8
• Bolt circle diameter: 139.7 mm / 5.5 in

Detailed Product Overview

This InMotion wheel bearing and hub assembly is manufactured with high-precision processes and strict quality-control standards to match the original front hub layout on the Hummer H3 and Hummer H3T. The WA515128 uses OE-based dimensions for proper fitment, stable wheel mounting, and consistent bearing performance. It is a direct replacement for the front hub assembly on 2009-2010 Hummer H3 and 2009-2010 Hummer H3T models.

This part cross-references Monroe Shocks & Struts (e.g., 172286, 182286) for the same application.

Common Problems This Part Can Address

• Front wheel bearing noise or growling
• Excessive wheel play or looseness at the hub
• ABS warning light caused by a failing hub sensor assembly
• Uneven wheel mounting caused by worn hub surfaces
• Vibration or rough rotation from a damaged front hub assembly

Installation Notes and Tips

Confirm the vehicle is a 2009-2010 Hummer H3 or 2009-2010 Hummer H3T with front application before ordering. Verify spline count, bolt circle diameter, and pilot dimensions against the original part to ensure correct installation. Clean the mounting surface and inspect related suspension and brake components during replacement.

Quality Assurance

InMotion manufactures this hub assembly using OE data, precise measurements, and controlled production standards to support accurate fitment and dependable service life.
