Koyorad A2430 Radiator

Koyorad A2430 Radiator for Suzuki Cooling Repair

The Koyorad A2430 radiator is an OE-equivalent replacement built for 2001-2003 Suzuki Grand Vitara and 2002-2003 Suzuki XL-7 applications. It combines an aluminum core with plastic tanks and includes an internal transmission oil cooler for direct-fit cooling system service.

Key Features

• Fits 2001-2003 Suzuki Grand Vitara, N/A
• Fits 2002-2003 Suzuki XL-7, N/A
• Aluminum core with 1-row construction
• Plastic tank design for OE-style replacement fitment
• Internal transmission oil cooler included
• Transmission oil cooler diameter: 1.125 in.
• Inlet and outlet diameter: 1.375 in.
• Core dimensions: 16.75 in. height, 24.5 in. width, 1 in. thickness

Detailed Description

Built for Suzuki Grand Vitara and Suzuki XL-7 cooling system replacement, the Koyorad A2430 radiator is engineered as an OE-equivalent unit for straightforward service. The aluminum core supports efficient heat transfer, while the plastic tank construction matches common factory-style radiator design. With an included internal transmission oil cooler, this radiator is suited for vehicles that route transmission fluid through the radiator assembly. The Koyorad A2430 part number is a useful reference when sourcing a direct replacement radiator for these Suzuki models.

Common Problems This Radiator Can Address

• Leaking radiator tanks or core seams
• Overheating caused by restricted or damaged radiator passages
• Transmission cooler leakage within the radiator assembly
• Cracked or aged plastic end tanks
• Reduced cooling performance from a worn factory radiator

Installation Notes and Tips

Confirm inlet and outlet hose sizes before installation and verify transmission cooler line routing on the vehicle. Flush the cooling system, inspect hoses and clamps, and replace worn coolant components during radiator service. The Koyorad A2430 should be matched to the listed Suzuki Grand Vitara and Suzuki XL-7 fitment before installation. The part number A2430 can also be used to verify application during ordering and service lookup.

Quality Assurance

Koyorad states that its radiators are built as OE-equivalent replacements using technical manufacturing experience focused on correct fit and dependable replacement performance. This radiator is produced to support factory-style cooling system service for the listed Suzuki applications.
