KYB 3340124 Suspension Strut - Front Left
| Brand | KYB 36992 |
|---|---|
| Bolt Hole Quantity | 4 |
| Bolt Thread | M10 x 1.5 Hole |
| Clutch Maximum Diameter | 7.2 |
| Clutch Type | C - Heavy Duty |
| Color | Raw Aluminum in Color |
| Description | Fan Clutches |
| Dia. IN | 7.2 |
| Distance From Clutch To Mounting Flange | 1.63 |
| Electronic Clutch? | Non Electronic |
| Fan Bolt Circle IN | 3.25 |
| Fan Bolt Circle MM | 82.6 |
| Material | Aluminum |
| Meets / Exceeds OEM? | Yes |
| Mount Dia. IN | 2.43 |
| Mount Dia. MM | 62 |
| Mounting Hardware? | Not Included |
| Mounting Hole Quantity | 4 |
| Mounting Type | Flange |
| New or Reman | New |
| Overall Dia. MM | 182.9 |
| Overall Height IN | 3.34 |
| Overall Height MM | 84.8 |
| Performance Rated? | Yes |
| Pilot Depth IN | 1.03 |
| Pilot Depth MM | 26.2 |
| Pilot Dia. IN | 0.63 |
| Rotation | REV |
| Style | Heavy Duty |
| Type | Thermal |
| Use Type | Heavy |
| Product line | Excel-G |
| Fits | —11 vehicles |
OEA replacement. Restores original performance with OE-quality components.
Twin-tube design. Nitrogen gas-charged for consistent damping and control.
Triple-lip fluid seal. Helps reduce oil and gas leakage over time.
Cross-references Acura 51621TZ4A02, Acura 51621TZ4A03 and Acura 51621TZ3305 for the same application. See all 16.
KYB Excel-G Front Left Strut for Accord and TLX
KYB Excel-G struts are built to restore original ride control, stability, braking response, lane-change behavior, and handling. This KYB Excel-G suspension strut, part number 3340124, is a front left replacement for select Honda Accord and Acura TLX applications.
Key Features
- OE-style replacement choice for Asian vehicles
- Restores designed control and handling for Honda Accord and Acura TLX
- Nitrogen gas-charged, twin-tube construction
- Triple-lip fluid seal helps reduce oil and gas leakage
- Vehicle-specific, hand-assembled damping valves manage tire contact, steering response, and body movement
- Strong strut body and bracket design helps minimize flex and maintain alignment
- Internal rebound spring and R-stop included in the design
- Made in the USA
Product Details
KYB Excel-G is KYB’s OEA-style replacement line, produced on the same OE assembly lines and using OE-quality components to return the suspension to its original calibrated performance. Part number 3340124 is engineered for the front left position on 2015-2020 Acura TLX and 2013-2017 Honda Accord applications. This part cross-references Monroe Shocks & Struts 72971 for the same application.
What This Strut Helps Address
- Excessive bounce or poor ride control
- Reduced steering response during lane changes
- Front-end instability under braking
- Uneven tire contact caused by worn damping
- Noise and vibration from aged suspension components
Installation Notes
Fits 2015-2020 Acura TLX, front left. Fits 2013-2017 Honda Accord, front left. Replace the suspension strut and coil spring assembly according to the manufacturer’s instructions. KYB recommends new strut mounts, part number SM5849, to reduce noise and vibration, and a KYB strut boot, part number SB101, to help protect the strut from dirt, debris, and salt.
Quality Assurance
KYB is a major OE supplier to vehicle manufacturers, and Excel-G is built to restore original, designed suspension performance rather than alter it. The part number 3340124 is manufactured to KYB’s OE-quality standards for consistent fit and damping control.
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2020 | Acura | TLX | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2019 | Acura | TLX | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2018 | Acura | TLX | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2017 | Acura | TLX | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2017 | Honda | Accord | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2016 | Acura | TLX | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2016 | Honda | Accord | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2015 | Acura | TLX | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2015 | Honda | Accord | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2014 | Honda | Accord | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2013 | Honda | Accord | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
