KYB 335081 Suspension Strut - Front Left
| Brand | KYB 710436 |
|---|---|
| Helix Type | Clockwise-Spiral Lip Design |
| Housing Bore (Inch) | 2.067 |
| Housing Bore (MM) | 52.500 |
| Inside Diameter | 1.594 |
| Inside Diameter | 40.500 |
| Material | Polyacrylate |
| Outside Diameter | 2.075 |
| Outside Diameter | 52.700 |
| Outside Diameter (Inch) | 2.075 |
| Outside Diameter (mm) | 52.700 |
| Part Description | Oil Seal |
| Series | 710400 |
| Shaft (Inch) | 1.594 |
| Shaft (MM) | 40.500 |
| Thickness | 0.236 |
| Thickness | 6.000 |
| Type | 35 |
| Unit of Dimension | Inch |
| Width (Inch) | 0.236 |
| Width (mm) | 6.000 |
| Product line | Excel-G |
| Fits | —12 vehicles |
OE replacement choice. Restores original control and handling with OE-quality components.
Twin-tube design. Nitrogen gas-charged construction helps maintain consistent damping.
Triple-lip fluid seal. Helps reduce the chance of oil and gas leaking out.
Cross-references Monroe Shocks & Struts 72683, Scion 4852080261 and Scion 4852080343 for the same application. See all 5.
KYB Excel-G Front Left Strut for Prius V and tC
The KYB Excel-G 335081 is a front left suspension strut built to restore original ride control, steering response, and body stability. It is a direct OE-style replacement for select Toyota Prius V and Scion tC applications, with vehicle-specific damping calibrated for factory handling characteristics.
Key Features
- OE-style replacement for Asian vehicles, including Toyota and Scion applications
- Nitrogen gas-charged, twin-tube design for consistent damping performance
- Triple-lip fluid seal helps reduce oil and gas leakage
- Hand-assembled, vehicle-specific damping valves manage tire contact, steering response, and body movement
- Strong strut body and bracket design helps minimize flex and maintain alignment
- R-stop design included; dust cover, internal rebound spring, and B-stop are not included
- Upper mount thread specification: 14x1.50
Product Details
KYB Excel-G is the brand’s OE replacement line, built on the same assembly lines used for original equipment production and calibrated to return the suspension to designed performance rather than change it. Part number 335081 is a front left suspension strut for 2012-2017 Toyota Prius V and 2011-2016 Scion tC applications. This part cross-references Monroe Shocks & Struts 72683 for the same application.
Common Problems This Strut Can Address
- Excessive front-end bounce or oscillation
- Loose or delayed steering response
- Reduced stability during lane changes and braking
- Uneven tire contact caused by worn damping control
- Suspension noise or handling changes from a worn front left strut
Installation Notes
Fits 2012-2017 Toyota Prius V, front left. Fits 2011-2016 Scion tC, front left. Replace the suspension strut and coil spring assembly according to the manufacturer’s instructions. Verify the upper mount thread specification and confirm suspension condition before installation. For added protection, KYB recommends a strut boot, part number SB112.
Quality Assurance
KYB is a major OE shock and strut supplier, and Excel-G is produced using OE-quality components with factory-style calibration. The design is intended to preserve original vehicle control characteristics for Toyota Prius V and Scion tC suspension service.
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2017 | Toyota | Prius V | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2016 | Scion | tC | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2016 | Toyota | Prius V | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2015 | Scion | tC | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2015 | Toyota | Prius V | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2014 | Scion | tC | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2014 | Toyota | Prius V | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2013 | Scion | tC | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2013 | Toyota | Prius V | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2012 | Scion | tC | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2012 | Toyota | Prius V | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2011 | Scion | tC | Front Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
