KYB 339255 Suspension Strut - Front Right
| Brand | KYB 500.13420 |
|---|---|
| Friction Material Attachment | Integrally Molded |
| Friction Material Composition | Ceramic |
| Hardware Kit Number [cntrc] | 117.33040 |
| Inner Pad Height | 3.189 |
| Inner Pad Height | 81.000 |
| Inner Pad Overall Thickness | 0.677 |
| Inner Pad Overall Thickness | 17.200 |
| Inner Pad Width | 7.402 |
| Inner Pad Width | 188.000 |
| Mounting Hardware Included | Yes |
| Outer Pad Height | 2.906 |
| Outer Pad Height | 73.800 |
| Outer Pad Overall Thickness | 0.724 |
| Outer Pad Overall Thickness | 18.400 |
| Outer Pad Width | 7.402 |
| Outer Pad Width | 188.000 |
| Pad Quantity | 4 |
| Pad Shims Included | Yes |
| Pad Wear Sensor Included | No |
| Prepared For Pad Wear Sensor | Yes |
| Weight [cntrc] kgs | 2.18 |
| Weight [cntrc] lbs | 4.80 |
| Product line | Excel-G |
| Fits | —13 vehicles |
OEA replacement. Restores original performance with OE-quality components and calibration.
Twin-tube design. Nitrogen gas-charged construction helps maintain consistent damping.
Triple lip fluid seal. Helps reduce the chance of oil and gas leakage.
Cross-references Gabriel G52039, Honda 51605SNXA01 and Monroe Shocks & Struts 72284 for the same application. See all 3.
KYB Excel-G Front Right Strut for Civic
The KYB Excel-G 339255 is a front right suspension strut for 2006-2011 Honda Civic models. Built to restore original ride control and steering response, it is an OE-style replacement for drivers who want factory-like handling on the road.
Key Features
- Fits 2006-2011 Honda Civic, front right
- KYB Excel-G line calibrated to restore original suspension performance
- Nitrogen gas-charged twin-tube design for consistent damping
- Triple-lip fluid seal helps reduce oil and gas leakage
- Vehicle-specific, hand-assembled damping valves manage tire contact, steering response, and body movement
- Strong strut body and bracket design helps minimize flex and maintain alignment
- Made in USA
- Upper mount type: 12X1.25
- Compressed length: 10.43 in; extended length: 17.32 in; stroke length: 6.89 in
Product Details
KYB Excel-G struts are built on the same OE assembly lines used for original equipment production and are classified as Original Equipment for the Aftermarket. The 339255 is engineered to restore the designed ride control of the Honda Civic rather than change suspension behavior, making it a practical choice for replacing a worn front right strut on 2006-2011 Honda Civic models. This part cross-references Monroe Shocks & Struts 72284 for the same application.
What This Strut Helps Address
- Excessive bouncing or poor damping after strut wear
- Loose steering feel or delayed lane-change response
- Reduced tire contact over bumps and uneven pavement
- Body movement that affects braking stability and cornering control
- Alignment drift caused by flex in a worn strut assembly
Installation Notes
Install on the front right position only for the listed Civic applications. Replace the suspension strut and coil spring assembly according to the manufacturer’s instructions. Verify all mounting dimensions, including the 12X1.25 upper mount type, before installation. KYB recommends protecting the new strut from dirt, debris, and salt with strut boot SB101.
Quality Assurance
KYB supplies shocks and struts to new vehicle manufacturers, and the Excel-G line is produced using OE-quality components to restore factory-designed performance. The strut body and bracket construction is designed to help maintain correct alignment and consistent control in daily driving.
| Year | Make | Model | Submodel | Body Type | Position | Notes |
|---|---|---|---|---|---|---|
| 2011 | Honda | Civic | DX | Coupe | Front Right | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2011 | Honda | Civic | Si | — | Front Right | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2010 | Honda | Civic | DX | Coupe | Front Right | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2010 | Honda | Civic | Si | — | Front Right | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2009 | Honda | Civic | DX | Coupe | Front Right | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2009 | Honda | Civic | Si | — | Front Right | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2008 | Honda | Civic | DX | Coupe | Front Right | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2008 | Honda | Civic | MUGEN Si | — | Front Right | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2008 | Honda | Civic | Si | — | Front Right | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2007 | Honda | Civic | DX | Coupe | Front Right | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2007 | Honda | Civic | Si | — | Front Right | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2006 | Honda | Civic | DX | Coupe | Front Right | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2006 | Honda | Civic | Si | — | Front Right | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
