KYB 339291 Suspension Strut - Rear Left
| Brand | KYB 090-034CD |
|---|---|
| Bolt Grade | 5.8 |
| Color | Silver |
| Describe Type | Pilot Point |
| Drain Method | Conventional |
| Gasket Or Seal Included | Yes |
| Gasket Type | Gasket |
| Head Drive Type | Hex |
| Head Size (SAE/Metric) | 15 mm |
| Length | 1 |
| Magnetic | No |
| Material | Carbon Steel |
| Oversized Thread | No |
| Package Contents | 1 Drain Plug; 1 Gasket |
| Program | Universal Oil |
| SAE or Metric | Metric |
| Socket Points | 6 |
| Special Tool Required | No |
| Thread Diameter | 12 |
| Thread Pitch | 1.75 |
| Thread Size | M12x1.75 |
| Thread Type | Metric |
| Threads Per Inch | 0 |
| Product line | Excel-G |
| Fits | —28 vehicles |
OEA replacement. Restores original ride control and handling.
Twin-tube design. Nitrogen gas-charged for consistent damping performance.
Triple-lip fluid seal. Helps reduce oil and gas leakage.
Cross-references Monroe Shocks & Struts 73034 and Toyota 4854009552 for the same application. See all 2.
KYB Excel-G Rear Left Strut for Camry
The KYB Excel-G 339291 is a suspension strut for the rear left position on select Toyota Camry models. Built to restore original ride control, it focuses on stability, steering response, and predictable handling rather than changing the vehicle’s factory feel.
Key Features
- Fits 2012-2017 Toyota Camry, rear left
- OE-style replacement choice for Asian vehicles
- Restores designed control and handling for the Toyota Camry
- Nitrogen gas-charged, twin-tube construction
- Triple-lip fluid seal helps reduce oil and gas leakage
- Vehicle-specific, hand-assembled damping valves manage tire contact, steering response, and body movement
- Strong strut body and bracket design helps minimize flex and maintain alignment
- Made in the USA
Product Details
KYB Excel-G is KYB’s OEA line, built on the same OE assembly lines and with OE-quality components used in original equipment production. For Toyota Camry rear suspension service, part number 339291 is engineered to return the vehicle to its intended damping characteristics, helping preserve ride control and the performance of electronic safety systems that rely on proper suspension, brake, and tire operation. This part cross-references Monroe Shocks & Struts 73034 for the same application.
Common Issues This Strut Can Address
- Excessive rear bounce or oscillation after bumps
- Reduced stability during lane changes or cornering
- Poor tire contact and uneven body movement over rough roads
- Delayed steering response caused by worn suspension damping
- Noise or fluid loss associated with a worn strut assembly
Installation Notes
Fits 2012-2017 Toyota Camry, rear left. Replace the suspension strut and coil spring assembly according to the manufacturer’s instructions. Verify upper mount type 14X1.50 and confirm all suspension components are inspected before installation. Part number 339291 should be matched to the correct rear left application before service.
Quality Assurance
KYB is a major OE supplier to vehicle manufacturers, and Excel-G is built to OE standards using OE-quality components for factory-style performance restoration. The KYB 339291 is designed for consistent damping and dependable fitment on the specified Toyota Camry application.
| Year | Make | Model | Submodel | Position | Notes |
|---|---|---|---|---|---|
| 2017 | Toyota | Camry | Hybrid LE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2017 | Toyota | Camry | Hybrid XLE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2017 | Toyota | Camry | LE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2017 | Toyota | Camry | XLE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2016 | Toyota | Camry | Hybrid LE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2016 | Toyota | Camry | Hybrid XLE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2016 | Toyota | Camry | LE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2016 | Toyota | Camry | XLE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2015 | Toyota | Camry | Hybrid LE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2015 | Toyota | Camry | Hybrid XLE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2015 | Toyota | Camry | LE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2015 | Toyota | Camry | XLE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2014 | Toyota | Camry | Hybrid LE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2014 | Toyota | Camry | Hybrid SE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2014 | Toyota | Camry | Hybrid XLE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2014 | Toyota | Camry | L | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2014 | Toyota | Camry | LE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2014 | Toyota | Camry | XLE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2013 | Toyota | Camry | Hybrid LE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2013 | Toyota | Camry | Hybrid XLE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2013 | Toyota | Camry | L | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2013 | Toyota | Camry | LE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2013 | Toyota | Camry | XLE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2012 | Toyota | Camry | Hybrid LE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2012 | Toyota | Camry | Hybrid XLE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2012 | Toyota | Camry | L | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2012 | Toyota | Camry | LE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
| 2012 | Toyota | Camry | XLE | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Excel-G |
