KYB 344291 Shock Absorber - Rear

Overview of KYB Excel-G Suspension Shock Absorber 344291

The KYB Excel-G Suspension Shock Absorber 344291 is designed specifically for Ford Windstar vehicles, providing reliable damping performance to restore original ride quality. This shock absorber features precise dimensions and mounting types to ensure proper fit and function.

• Compressed Length: 10.24 inches
• Extended Length: 15.55 inches
• Stroke Length: 5.31 inches
• Lower Mount Type: E2(12x38)
• Upper Mount Type: E2(12x38)
• Includes Dust Cover for protection
• R-stop included for controlled rebound
• No internal rebound spring or B-stop

Details on KYB Excel-G Shock Absorber Features

The KYB Excel-G line is engineered to restore the original handling and control of your Ford Windstar by matching the vehicle's factory specifications. This shock absorber, part number 344291, offers a compressed length of 10.24 inches and an extended length of 15.55 inches, with a stroke length of 5.31 inches to accommodate suspension travel. Both the upper and lower mounts use the E2(12x38) type, ensuring a secure and precise fit. The inclusion of a dust cover helps protect the internal components from dirt and debris, extending the service life of the shock absorber. Additionally, the R-stop feature provides controlled rebound damping, improving ride stability without the use of an internal rebound spring or B-stop.

Compatible Vehicles and Applications

This KYB Excel-G shock absorber 344291 is compatible with Ford Windstar models, designed to replace worn or damaged suspension shock absorbers. It is suitable for addressing issues such as:

• Excessive bouncing or poor ride comfort
• Reduced vehicle stability during cornering
• Uneven tire wear caused by suspension problems
• Increased stopping distances due to poor shock absorption
• Noise or vibration from worn suspension components

Installation Notes and Tips

When installing the KYB Excel-G shock absorber 344291 on a Ford Windstar, ensure the vehicle is securely lifted and supported. Verify that the upper and lower mounts correspond to the E2(12x38) specifications for proper alignment. It is recommended to replace shocks in pairs to maintain balanced handling. Inspect related suspension components for wear during installation and replace as necessary. The included dust cover should be positioned correctly to protect the shock absorber shaft from contaminants.

Quality Assurance and Warranty

KYB Excel-G shock absorbers are manufactured to meet or exceed OEM standards, providing consistent performance and durability. This part number 344291 undergoes rigorous quality control to ensure reliability. While specific warranty details may vary, KYB typically offers a limited warranty covering defects in materials and workmanship. Refer to KYB's official documentation for exact warranty terms.
