KYB SR4086 Suspension Strut and Coil Spring Assembly - Rear Left
| Brand | KYB 203-FF |
|---|---|
| Bore (Inch) | 0.669 |
| Bore (mm) | 17.000 |
| Design | Single Row Radial |
| Inner Race Bore (Inch) | 0.669 |
| Inner Race Bore (MM) | 17.000 |
| Inner Race Outside Diameter (Inch) | 5.512 |
| Inner Race Outside Diameter (MM) | 140.000 |
| Inner Race Radius (Inch) | 0.024 |
| Inner Race Radius (MM) | 0.610 |
| Inner Race Width (Inch) | 0.472 |
| Inner Race Width (MM) | 12.000 |
| Outer Race Outside Diameter (Inch) | 1.575 |
| Outer Race Outside Diameter (MM) | 40.000 |
| Outer Race Radius (Inch) | 0.024 |
| Outer Race Radius (MM) | 0.610 |
| Outer Race Width (Inch) | 0.472 |
| Outer Race Width (MM) | 12.000 |
| Outside Diameter (Inch) | 1.575 |
| Outside Diameter (mm) | 40.000 |
| Part Description | Ball Bearing |
| Series | 200 |
| Type | A-9 |
| Width (Inch) | 0.472 |
| Width (mm) | 12.000 |
| Product line | Strut-Plus |
| Fits | —5 vehicles |
OE restoring design. Helps return handling, control, and ride height to OE specifications.
Pre-assembled for results. Engineered for exact fitment and professional installation.
Application-specific damping. Precision valves and a stronger steel outer shell improve control.
Cross-references Monroe Shocks & Struts 172208 and Monroe Shocks & Struts 182208 for the same application. See all 2.
KYB Strut-Plus Rear Left Assembly for Toyota
The KYB Strut-Plus SR4086 is a pre-assembled suspension strut and coil spring assembly built for rear left applications on select Toyota models. It combines an OE-restoring KYB strut with a high carbon steel coil spring to help return ride height, handling response, and vehicle stability to factory specifications.
For 2004-2006 Toyota Camry and 2005-2006 Toyota Avalon rear left service, this KYB Strut-Plus assembly is engineered for exact fitment and professional results. The SR4086 is also designed with vehicle systems in mind, including electronic stability and braking controls.
Key Features
- OE-style replacement choice for Asian vehicles
- Includes a KYB Excel-G strut with application-specific damping valves
- Stronger steel outer shell for added structural support
- High carbon steel coil spring developed around vehicle corner weights
- Pre-assembled for exact fitment and professional installation
- Side-specific design for the rear left position
- Engineered to help maintain performance with ESC, ABS, and related safety systems
- Assembled in the USA
- Recipient of a 2018 import aftermarket industry award
Detailed Description
KYB is an original equipment supplier, and the Strut-Plus line is built to restore the handling and control characteristics expected from the vehicle’s suspension. The SR4086 uses a KYB strut paired with a coil spring selected to help restore ride height within OE specifications. This makes it a practical choice for drivers addressing worn rear suspension components on a Toyota Camry or Toyota Avalon.
This part cross-references Monroe Shocks & Struts (e.g., 172208, 182208) for the same application. Search terms such as KYB SR4086 rear left strut assembly, Toyota Camry rear left strut and coil spring assembly, and Toyota Avalon rear left suspension strut assembly align with this part.
What It Helps Address
- Excessive rear suspension bounce or poor damping control
- Sagging ride height from worn coil spring components
- Reduced steering and body control during cornering
- Noisy or unstable rear suspension operation
- Suspension wear that can affect ESC and ABS performance
Installation Notes and Tips
Fits 2006 Toyota Avalon, rear left. Fits 2005 Toyota Avalon, rear left. Fits 2004-2006 Toyota Camry, rear left. Replace the suspension strut and coil spring assembly according to the manufacturer’s instructions. Verify rear left position, model year, and trim-specific suspension details before installation.
Quality Assurance
KYB builds Strut-Plus assemblies as OE-restoring suspension components using application-specific damping and spring specifications. The SR4086 is assembled in the USA and engineered around the vehicle’s original suspension geometry and electronic safety system requirements.
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2006 | Toyota | Avalon | Rear Left | Recommended OEM Replacement; TO 1/06; Strut-Plus |
| 2006 | Toyota | Camry | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Strut-Plus |
| 2005 | Toyota | Avalon | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Strut-Plus |
| 2005 | Toyota | Camry | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Strut-Plus |
| 2004 | Toyota | Camry | Rear Left | Replace suspension strut and coil spring assembly according to manufacturer's instructions.; Strut-Plus |
