Luk 07-909 Clutch Kit
| Brand | Luk 07-909 |
|---|---|
| Clutch Diameter | 9-5/8" |
| Clutch Disc Diameter | 11-1/16" |
| Clutch Disc Spline Quantity | 10 |
| Clutch Plate Facing Outer Diameter | 11" |
| Input Shaft Diameter | 1-1/16" |
| Kit contents | Cover Assembly, Clutch Disc, all Necessary Pilots, Accessory Pack , Release Bearing Not included |
| Number of clutch disc springs | 4 |
| Pressure Plate Type | Push Type Diaphragm |
| Fits | Ford · 32 vehicles |
OE supplier pedigree. Built to the performance specs used for original-equipment applications.
Complete clutch kit. Includes the cover assembly, clutch disc, pilots, and accessory pack.
Push-type diaphragm. Engineered for smooth, consistent clutch engagement.
Cross-references Sachs K0064-05CB, 07-097SR300 and 383046 for the same application. See all 7.
$261.46Free shipping
In stock · usually ships same day before 1pm CST
Step 1 — Confirm fitment
Free return shipping if it doesn't fit when you check fitment here first.
Select your vehicle to confirm fitment
Verify this part fits before purchasing — free returns if it doesn't
Step 2 — Quantity
Free shipping to the continental U.S.
Free returns within 60 days if it doesn't fit when fitment is verified.
Not what you need? See all Clutch Kit options
LuK 07-909 Clutch Kit Overview
LuK 07-909 is a transmission clutch kit built for select Ford heavy-duty applications from 1993-1996. It combines OE-style engineering with application-specific specifications for Ford Bronco, F-150, F-250, and F-350 manual transmission service.
For Ford Bronco clutch replacement and Ford F-150 clutch kit service, this LuK assembly is specified with a push type diaphragm pressure plate and a 10-spline disc setup. The kit is built around the dimensions and release characteristics needed for the listed Ford truck applications.
Key Features
- Part number: 07-909
- Push type diaphragm pressure plate design
- Clutch disc diameter: 11-1/16 in.
- Clutch diameter: 9-5/8 in.
- Clutch disc spline quantity: 10
- Input shaft diameter: 1-1/16 in.
- Clutch plate facing outer diameter: 11 in.
- Four-spring clutch disc construction
- Kit contents include cover assembly, clutch disc, all necessary pilots, and accessory pack
Detailed Description
LuK develops OE-level performance specifications for individual vehicle applications, and this 07-909 clutch kit reflects that application-specific approach. It is engineered for manual transmission service in 1993-1996 Ford Bronco, Ford F-150, Ford F-250, and Ford F-350 models listed in the fitment data. The design uses a push type diaphragm pressure plate and a 10-spline disc to match the required drivetrain dimensions.
This part cross-references Sachs K0064-05CB for the same application. If you are searching for a LuK clutch kit for Ford F-150 1993-1996 or a replacement clutch assembly for Ford Bronco and Ford Super Duty-era trucks in the listed years, 07-909 is the catalog reference to verify against your vehicle’s transmission and clutch specifications.
What This Clutch Kit Helps Address
- Clutch slip under load
- Difficulty engaging gears
- Chatter or shudder during takeoff
- Worn clutch disc friction surfaces
- Pressure plate wear affecting pedal feel and release
Installation Notes
- Verify transmission and clutch dimensions before installation.
- Follow the vehicle-specific notes in the fitment data for heavy-duty applications.
- Do not lubricate the bearing where the application notes prohibit it.
- Some listed Ford applications include additional service notes for slave cylinder release bearing and related components.
- Confirm spline count, input shaft diameter, and clutch diameter match the original setup before assembly.
Quality Assurance
LuK is an original-equipment supplier with extensive in-house manufacturing content, and its RepSet clutch components are built around OE application data. That engineering background supports consistent fitment and serviceability for the listed Ford Bronco, Ford F-150, Ford F-250, and Ford F-350 applications.
This part fits 32 vehicles
Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
| Year | Make | Model | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|
| 1996 | Ford | Bronco | 5.0L | V8 | N/A | Heavy-Duty; Refer to LB178 regarding hard pedal/release problems.; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1996 | Ford | F-150 | 5.0L | V8 | N/A | Heavy-Duty; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1996 | Ford | F-150 | 4.9L | L6 | N/A | Heavy-Duty; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1996 | Ford | F-250 | 5.0L | V8 | N/A | Heavy-Duty; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1996 | Ford | F-250 | 4.9L | L6 | N/A | Heavy-Duty; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1996 | Ford | F-350 | 4.9L | L6 | N/A | Heavy-Duty; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1995 | Ford | Bronco | 5.0L | V8 | N/A | Heavy-Duty; Refer to LB178 regarding hard pedal/release problems.; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1995 | Ford | F-150 | 5.0L | V8 | N/A | Heavy-Duty; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1995 | Ford | F-150 | 4.9L | L6 | N/A | Heavy-Duty; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1995 | Ford | F-250 | 5.0L | V8 | N/A | Heavy-Duty; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1995 | Ford | F-250 | 4.9L | L6 | N/A | Heavy-Duty; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1995 | Ford | F-350 | 4.9L | L6 | N/A | Heavy-Duty; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1994 | Ford | Bronco | 5.0L | V8 | N/A | Heavy-Duty; Refer to LB178 regarding hard pedal/release problems.; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1994 | Ford | Bronco | 5.8L | V8 | N/A | Heavy-Duty; Do not lubricate bearing. Refer to LB192. |
| 1994 | Ford | F-150 | 4.9L | L6 | N/A | 11" Clutch; Heavy-Duty; When upgrading to an 11-inch clutch, six grade 8 3/8"-16 X 1 " bolts with lock washers are required.; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1994 | Ford | F-150 | 5.0L | V8 | N/A | Heavy-Duty; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1994 | Ford | F-150 | 5.8L | V8 | N/A | Heavy-Duty; Refer to LB178 regarding hard pedal/release problems.; Replace driveshaft center support bearing plate with Ford part #F4TZ-4831A. Refer to LB150.; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1994 | Ford | F-250 | 4.9L | L6 | N/A | 11" Clutch; Heavy-Duty; When upgrading to an 11-inch clutch, six grade 8 3/8"-16 X 1 " bolts with lock washers are required.; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1994 | Ford | F-250 | 5.0L | V8 | N/A | Heavy-Duty; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1994 | Ford | F-250 | 5.8L | V8 | N/A | Heavy-Duty; Refer to LB178 regarding hard pedal/release problems.; Replace driveshaft center support bearing plate with Ford part #F4TZ-4831A. Refer to LB150.; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1994 | Ford | F-350 | 4.9L | L6 | N/A | 11" Clutch; Heavy-Duty; When upgrading to an 11-inch clutch, six grade 8 3/8"-16 X 1 " bolts with lock washers are required.; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1994 | Ford | F-350 | 5.8L | V8 | N/A | Heavy-Duty; Refer to LB178 regarding hard pedal/release problems.; Replace driveshaft center support bearing plate with Ford part #F4TZ-4831A. Refer to LB150.; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1993 | Ford | Bronco | 5.0L | V8 | N/A | Heavy-Duty; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1993 | Ford | Bronco | 5.8L | V8 | N/A | Heavy-Duty; Do not lubricate bearing. Refer to LB192. |
| 1993 | Ford | F-150 | 4.9L | L6 | N/A | 11" Clutch; Heavy-Duty; When upgrading to an 11-inch clutch, six grade 8 3/8"-16 X 1 " bolts with lock washers are required.; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1993 | Ford | F-150 | 5.0L | V8 | N/A | Heavy-Duty; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1993 | Ford | F-150 | 5.8L | V8 | N/A | Heavy-Duty; Refer to LB178 regarding hard pedal/release problems.; Replace driveshaft center support bearing plate with Ford part #F4TZ-4831A. Refer to LB150.; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1993 | Ford | F-250 | 4.9L | L6 | N/A | 11" Clutch; Heavy-Duty; When upgrading to an 11-inch clutch, six grade 8 3/8"-16 X 1 " bolts with lock washers are required.; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1993 | Ford | F-250 | 5.0L | V8 | N/A | Heavy-Duty; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1993 | Ford | F-250 | 5.8L | V8 | N/A | Heavy-Duty; Refer to LB178 regarding hard pedal/release problems.; Replace driveshaft center support bearing plate with Ford part #F4TZ-4831A. Refer to LB150.; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1993 | Ford | F-350 | 4.9L | L6 | N/A | 11" Clutch; Heavy-Duty; When upgrading to an 11-inch clutch, six grade 8 3/8"-16 X 1 " bolts with lock washers are required.; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| 1993 | Ford | F-350 | 5.8L | V8 | N/A | Heavy-Duty; Refer to LB178 regarding hard pedal/release problems.; Replace driveshaft center support bearing plate with Ford part #F4TZ-4831A. Refer to LB150.; Do not lubricate bearing. Refer to LB192.; Refer to LB194 regarding the slave cylinder release bearing. |
| No rows match your filter. | ||||||
Directly replaces or cross-references 7 part numbers
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
Sachs — K0064-05CB07-097SR30038304611079096283145770HP64-1KPK31102B-2
