OE Quality
60-Day Returns
Luk 22-031 Clutch Kit
Overview of Luk Transmission Clutch Kit 22-031
The Luk Transmission Clutch Kit 22-031 is designed specifically for Volvo C70, S70, and V70 models. This kit includes all necessary components to ensure a reliable clutch replacement, featuring a self-adjusting pressure plate and a clutch disc with precise dimensions for optimal performance.
- Self-adjusting pressure plate for consistent clutch engagement
- Clutch disc diameter of 9-7/16 inches (9.4488 inches)
- Input shaft diameter of 7/8 inch with 20 spline clutch disc
- Includes cover assembly, clutch disc, slave cylinder, and all necessary pilots
- Zero clutch disc springs for a direct engagement feel
Detailed Product Description
The Luk 22-031 Transmission Clutch Kit is engineered to meet the exact specifications required by Volvo C70, S70, and V70 vehicles. The self-adjusting pressure plate maintains proper clutch pedal feel and engagement over time, reducing the need for manual adjustments. The clutch disc measures 9-7/16 inches in diameter and features 20 splines on the disc, matching the 7/8 inch input shaft diameter for a precise fit. This kit also includes a slave cylinder and all necessary pilot components, providing a comprehensive solution for clutch replacement or repair.
Applications and Common Issues Addressed
- Replacement of worn or damaged clutch components in Volvo C70, S70, and V70
- Resolving clutch slippage due to pressure plate wear
- Fixing inconsistent clutch pedal engagement or adjustment problems
- Addressing clutch chatter or vibration caused by faulty clutch discs
- Restoring proper transmission input shaft engagement
Installation Notes and Tips
When installing the Luk 22-031 clutch kit, ensure the flywheel surface is inspected and resurfaced if necessary to prevent premature wear. Proper alignment of the clutch disc splines with the input shaft is critical for smooth operation. The self-adjusting pressure plate reduces the need for manual adjustments, but verify clutch pedal free play after installation. Bleed the hydraulic system thoroughly to ensure the slave cylinder operates correctly.
Quality Assurance and Warranty
Luk transmission components are manufactured to meet OEM standards, ensuring durability and reliable performance. The 22-031 clutch kit undergoes rigorous quality control to maintain consistent fit and function. Warranty coverage details should be confirmed with the point of purchase or manufacturer documentation.
| Brand | Luk |
| Part Number | 22-031 |
| Clutch Diameter | 9.448818898 |
| Clutch Disc Diameter | 9-7/16" |
| Clutch Disc Spline Quantity | 20 |
| Clutch Plate Facing Outer Diameter | 9-7/16" |
| Input Shaft Diameter | 7/8" |
| Kit contents | Cover Assembly, Clutch Disc, Slave Cylinder,all Necessary Pilots, Accessory Pack |
| Number of clutch disc springs | 0 |
| Pressure Plate Type | Self Adjusting |
This part fits 12 vehicles. Search below:
| Year | Make | Model | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|
| 2002 | Volvo | C70 | 2.3L | L5 | N/A | This Release Fork includes the Release Fork and the Release Bearing. These two components must only be used together.; Refer to LB163 regarding internal slave cylinders |
| 2001 | Volvo | C70 | 2.3L | L5 | N/A | This Release Fork includes the Release Fork and the Release Bearing. These two components must only be used together.; Refer to LB163 regarding internal slave cylinders |
| 2000 | Volvo | C70 | 2.3L | L5 | N/A | This Release Fork includes the Release Fork and the Release Bearing. These two components must only be used together.; Refer to LB163 regarding internal slave cylinders |
| 2000 | Volvo | S70 | 2.3L | L5 | N/A | This Release Fork includes the Release Fork and the Release Bearing. These two components must only be used together.; Refer to LB163 regarding internal slave cylinders |
| 2000 | Volvo | V70 | 2.3L | L5 | N/A | This Release Fork includes the Release Fork and the Release Bearing. These two components must only be used together.; Refer to LB163 regarding internal slave cylinders |
| 1999 | Volvo | C70 | 2.3L | L5 | N/A | This Release Fork includes the Release Fork and the Release Bearing. These two components must only be used together.; Refer to LB163 regarding internal slave cylinders |
| 1999 | Volvo | S70 | 2.4L | L5 | N/A | This Release Fork includes the Release Fork and the Release Bearing. These two components must only be used together.; Refer to LB163 regarding internal slave cylinders |
| 1999 | Volvo | S70 | 2.3L | L5 | N/A | This Release Fork includes the Release Fork and the Release Bearing. These two components must only be used together.; Refer to LB163 regarding internal slave cylinders |
| 1999 | Volvo | V70 | 2.3L | L5 | N/A | This Release Fork includes the Release Fork and the Release Bearing. These two components must only be used together.; Refer to LB163 regarding internal slave cylinders |
| 1998 | Volvo | C70 | 2.3L | L5 | N/A | This Release Fork includes the Release Fork and the Release Bearing. These two components must only be used together.; Refer to LB163 regarding internal slave cylinders |
| 1998 | Volvo | S70 | 2.3L | L5 | N/A | From Chassis #460000; This Release Fork includes the Release Fork and the Release Bearing. These two components must only be used together.; Refer to LB163 regarding internal slave cylinders |
| 1998 | Volvo | V70 | 2.3L | L5 | N/A | From Chassis #460000; This Release Fork includes the Release Fork and the Release Bearing. These two components must only be used together.; Refer to LB163 regarding internal slave cylinders |
* Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
This part directly replaces or is cross-referenced with the following part numbers:
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
