Luk LMC203 Clutch Master Cylinder
| Brand | Luk LMC203 |
|---|---|
| Fits | Jeep · 7 vehicles |
Hydraulic clutch release. Built for modern clutch systems with LuK expertise behind it.
Push rod included. Ready for installation with the push rod supplied.
New part. Fresh replacement component for dependable service.
Cross-references AMS Automotive M0108, Centric Parts 136.63008 and Dayco 72203 for the same application. See all 12.
Clutch Master Cylinder for Jeep Manual Transmissions
The LuK LMC203 clutch master cylinder is a new hydraulic replacement for manual transmission clutch release systems. It is built for Jeep Cherokee, Comanche, and Wagoneer applications from the mid-1980s, with installation instructions and a push rod included for a more complete service job.
Key Features
- New clutch master cylinder for hydraulic clutch actuation
- Installation instructions included
- Push rod included
- Pre-filled fluid: No
- Pre-bled system: No
- Heat shield included: No
- Clutch slave cylinder not included
Product Details
LuK has extensive experience in hydraulic clutch release systems, and the LMC203 reflects that background with a service replacement focused on restoring clutch pedal hydraulic function. This part number is used in manual transmission applications where the master cylinder transfers pedal movement into hydraulic pressure for clutch engagement and release. The LMC203 cross-references AMS Automotive M0108 and Dorman First Stop CM39723 for the same application. For Jeep Cherokee and Jeep Wagoneer service, the LMC203 is a direct-fit style replacement for the listed model years.
What It Helps Fix
- Soft or inconsistent clutch pedal feel
- Loss of hydraulic pressure in the clutch release system
- Difficulty disengaging the clutch
- Fluid leakage at the master cylinder
- Clutch pedal travel problems caused by a worn hydraulic master cylinder
Installation Notes
Fits 1984-1986 Jeep Cherokee, N/A. Fits 1986 Jeep Comanche, N/A. Fits 1986 Jeep Wagoneer, N/A. Fits 1984-1985 Jeep Wagoneer, N/A. Installation instructions are included, and the push rod is included. This unit is not pre-filled and is not pre-bled, so the hydraulic system will need to be filled and bled during installation. Refer to LB122 for Jeep Cherokee and Jeep Wagoneer applications regarding the plastic pivot on the end of the slave cylinder push rod.
Quality Assurance
LuK, part number LMC203, is a new replacement component backed by Schaeffler’s experience in clutch release system development. It is built for hydraulic clutch service in Jeep manual transmission applications and supplied as a fresh part for repair work.
| Year | Make | Model | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|
| 1986 | Jeep | Cherokee | 2.5L | L4 | N/A | Refer to LB122 regarding plastic pivot on the end of the slave cylinder push rod. |
| 1986 | Jeep | Comanche | 2.5L | L4 | N/A | — |
| 1986 | Jeep | Wagoneer | 2.5L | L4 | N/A | Refer to LB122 regarding plastic pivot on the end of the slave cylinder push rod. |
| 1985 | Jeep | Cherokee | 2.5L | L4 | N/A | Refer to LB122 regarding plastic pivot on the end of the slave cylinder push rod. |
| 1985 | Jeep | Wagoneer | 2.5L | L4 | N/A | — |
| 1984 | Jeep | Cherokee | 2.5L | L4 | N/A | Refer to LB122 regarding plastic pivot on the end of the slave cylinder push rod. |
| 1984 | Jeep | Wagoneer | 2.5L | L4 | N/A | — |
| No rows match your filter. | ||||||
