Luk LMC396 Clutch Master Cylinder
| Brand | Luk LMC396 |
|---|---|
| Fits | Scion, Toyota, and Pontiac · 63 vehicles |
Hydraulic clutch control. Built for smooth clutch release system operation.
Push rod included. Ready for a more complete installation.
Installation instructions included. Helps simplify the setup process.
Cross-references AMS Automotive M1664, Centric Parts 136.44004 and Dayco 72396 for the same application. See all 9.
Clutch Master Cylinder for Toyota and Scion
Restore hydraulic clutch operation with this LuK clutch master cylinder, part number LMC396. It is a new replacement unit with a push rod included and installation instructions included for a more straightforward service on select Toyota, Scion, and Pontiac applications.
- New clutch master cylinder for manual transmission hydraulic release systems
- Push rod included for proper pedal-to-cylinder connection
- Installation instructions included
- Pre-filled fluid: No
- Pre-bled system: No
- Heat shield included: No
- Clutch slave cylinder included: without clutch slave cylinder
Fitment and Application Details
Compatible with 2000-2005 Toyota Celica, 2002-2009 Toyota Camry, 2003-2008 Toyota Corolla, 2003-2008 Toyota Matrix, 2004-2008 Toyota Solara, 2003-2008 Pontiac Vibe, and 2005-2010 Scion tC. This LuK LMC396 clutch master cylinder is a direct-fit service part for manual transmission clutch hydraulic repair on these vehicles.
LuK has been a key name in the transition from mechanical to hydraulic clutch release systems, and Schaeffler’s experience in complete clutch release systems supports the engineering behind this replacement component. This part cross-references Sachs SH5260 for the same application.
What This Part Helps Fix
- Soft or inconsistent clutch pedal feel
- Difficulty disengaging the clutch
- Hydraulic fluid loss at the master cylinder
- Clutch pedal that sinks or does not return properly
- Shifting problems caused by clutch hydraulic failure
Installation Notes
Verify vehicle fitment by year, make, and model before installation. Because this unit is not pre-filled or pre-bled, the hydraulic system must be filled and bled after installation. The included push rod and instructions support replacement on manual transmission clutch systems.
Quality Assurance
LuK manufactures clutch release components with extensive experience in hydraulic clutch system development. Part number LMC396 is a new replacement clutch master cylinder built for service on the listed Toyota, Scion, and Pontiac applications.
| Year | Make | Model | Submodel | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|---|
| 2010 | Scion | tC | — | 2.4L | L4 | N/A | — |
| 2009 | Scion | tC | — | 2.4L | L4 | N/A | — |
| 2009 | Toyota | Camry | — | 3.5L | V6 | N/A | — |
| 2008 | Pontiac | Vibe | — | 1.8L | L4 | N/A | — |
| 2008 | Scion | tC | — | 2.4L | L4 | N/A | — |
| 2008 | Toyota | Camry | — | 3.5L | V6 | N/A | — |
| 2008 | Toyota | Corolla | — | 1.8L | L4 | N/A | — |
| 2008 | Toyota | Matrix | — | 1.8L | L4 | N/A | — |
| 2008 | Toyota | Solara | — | 2.4L | L4 | N/A | — |
| 2007 | Pontiac | Vibe | — | 1.8L | L4 | N/A | — |
| 2007 | Scion | tC | — | 2.4L | L4 | N/A | — |
| 2007 | Toyota | Camry | — | 3.5L | V6 | N/A | — |
| 2007 | Toyota | Corolla | — | 1.8L | L4 | N/A | — |
| 2007 | Toyota | Matrix | — | 1.8L | L4 | N/A | — |
| 2007 | Toyota | Solara | — | 2.4L | L4 | N/A | — |
| 2006 | Pontiac | Vibe | — | 1.8L | L4 | N/A | — |
| 2006 | Pontiac | Vibe | GT | 1.8L | L4 | N/A | — |
| 2006 | Scion | tC | — | 2.4L | L4 | N/A | — |
| 2006 | Toyota | Camry | — | 2.4L | L4 | N/A | — |
| 2006 | Toyota | Camry | — | 3.0L | V6 | N/A | — |
| 2006 | Toyota | Camry | — | 3.3L | V6 | N/A | — |
| 2006 | Toyota | Corolla | — | 1.8L | L4 | N/A | — |
| 2006 | Toyota | Corolla | XRS | 1.8L | L4 | N/A | — |
| 2006 | Toyota | Matrix | — | 1.8L | L4 | N/A | — |
| 2006 | Toyota | Solara | — | 2.4L | L4 | N/A | — |
| 2005 | Pontiac | Vibe | — | 1.8L | L4 | N/A | — |
| 2005 | Pontiac | Vibe | GT | 1.8L | L4 | N/A | — |
| 2005 | Scion | tC | — | 2.4L | L4 | N/A | — |
| 2005 | Toyota | Camry | — | 2.4L | L4 | N/A | — |
| 2005 | Toyota | Camry | — | 3.0L | V6 | N/A | — |
| 2005 | Toyota | Camry | — | 3.3L | V6 | N/A | — |
| 2005 | Toyota | Celica | GT | 1.8L | L4 | N/A | — |
| 2005 | Toyota | Celica | GTS | 1.8L | L4 | N/A | — |
| 2005 | Toyota | Corolla | — | 1.8L | L4 | N/A | — |
| 2005 | Toyota | Corolla | XRS | 1.8L | L4 | N/A | — |
| 2005 | Toyota | Matrix | — | 1.8L | L4 | N/A | — |
| 2005 | Toyota | Solara | — | 2.4L | L4 | N/A | — |
| 2004 | Pontiac | Vibe | — | 1.8L | L4 | N/A | — |
| 2004 | Pontiac | Vibe | GT | 1.8L | L4 | N/A | — |
| 2004 | Toyota | Camry | — | 2.4L | L4 | N/A | — |
| 2004 | Toyota | Camry | — | 3.0L | V6 | N/A | — |
| 2004 | Toyota | Camry | — | 3.3L | V6 | N/A | — |
| 2004 | Toyota | Celica | GT | 1.8L | L4 | N/A | — |
| 2004 | Toyota | Celica | GTS | 1.8L | L4 | N/A | — |
| 2004 | Toyota | Corolla | — | 1.8L | L4 | N/A | — |
| 2004 | Toyota | Matrix | — | 1.8L | L4 | N/A | — |
| 2004 | Toyota | Solara | — | 2.4L | L4 | N/A | — |
| 2003 | Pontiac | Vibe | — | 1.8L | L4 | N/A | — |
| 2003 | Pontiac | Vibe | GT | 1.8L | L4 | N/A | — |
| 2003 | Toyota | Camry | — | 2.4L | L4 | N/A | — |
| 2003 | Toyota | Camry | — | 3.0L | V6 | N/A | — |
| 2003 | Toyota | Celica | GT | 1.8L | L4 | N/A | — |
| 2003 | Toyota | Celica | GTS | 1.8L | L4 | N/A | — |
| 2003 | Toyota | Corolla | — | 1.8L | L4 | N/A | — |
| 2003 | Toyota | Matrix | — | 1.8L | L4 | N/A | — |
| 2002 | Toyota | Camry | — | 2.4L | L4 | N/A | — |
| 2002 | Toyota | Camry | — | 3.0L | V6 | N/A | — |
| 2002 | Toyota | Celica | GT | 1.8L | L4 | N/A | — |
| 2002 | Toyota | Celica | GTS | 1.8L | L4 | N/A | — |
| 2001 | Toyota | Celica | GT | 1.8L | L4 | N/A | — |
| 2001 | Toyota | Celica | GTS | 1.8L | L4 | N/A | — |
| 2000 | Toyota | Celica | GT | 1.8L | L4 | N/A | — |
| 2000 | Toyota | Celica | GTS | 1.8L | L4 | N/A | — |
