MAS Chassis CB74364 Suspension Control Arm and Ball Joint Assembly - Front Right Lower
| Brand | MAS Chassis CB74364 |
|---|---|
| Position | Front Right Lower |
| Grease Fitting Included | Yes |
| Bushings Included | Yes |
| Ball Joint Mounting Type | Press in |
| Ball Joint Stud Type | Threaded |
| Control Arm Material | Steel |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 2 |
| Adjustable | No |
| Control Arm Maximum Width | 450 |
| Control Arm Color | Black |
| Ball Joint Thread Diameter | 18 |
| Control Arm Maximum Length | 486 |
| Bushing Material | Rubber |
| Ball Joint Included | Yes |
| Ball Joint Installed | Yes |
| Control Arm Type | Casting/forged |
| Grade Type | Regular |
| Mounting Hole Diameter | 18.5 mm |
| Package Contents | 1 control arm; 1 castle nut; 1 cotter pin; 1 zerk fitting |
| Fits | Toyota · 30 vehicles |
Direct replacement. Matches original equipment for specific applications.
Steel construction. Forged and cast for dependable suspension support.
Ball joint installed. Includes bushings and mounting hardware for easier service.
Cross-references Delphi TC3568, Mevotech Original Grade GS86137 and Mevotech Supreme CMS86137 for the same application. See all 9.
OE-Style Front Right Lower Control Arm
MAS Chassis CB74364 is a suspension control arm and ball joint assembly for the front right lower position on select Toyota Tundra and Toyota Sequoia applications. It is built as a direct replacement for the original equipment design, with a focus on ride control, directional stability, and consistent suspension response.
Key Features
- Direct replacement suspension control arm and ball joint assembly
- Fits the front right lower position on select Toyota Tundra and Toyota Sequoia models
- Steel control arm construction with black finish
- Ball joint is included and installed
- Press-in ball joint mounting with threaded stud type
- Rubber bushings included for OE-style suspension isolation
- Grease fitting included for serviceability
- Mounting hardware included
Detailed Description
Built for specific Toyota truck and SUV applications, MAS Chassis CB74364 is engineered as a replacement for the original front right lower control arm assembly. The steel casting/forged construction, rubber bushings, and press-in ball joint design support stable suspension geometry and predictable handling characteristics. This part cross-references MOOG Chassis Products RK621303 for the same application.
Compatible with 2007-2021 Toyota Tundra, front right lower, and 2008-2022 Toyota Sequoia, front right lower. The CB74364 part number is also a useful reference when matching OE-style suspension components for these vehicles.
Common Problems This Part Can Address
- Excessive front-end looseness or wandering
- Clunking or knocking from the lower suspension area
- Uneven tire wear caused by worn control arm bushings or ball joint wear
- Reduced steering stability during braking or cornering
- Suspension play from a damaged or fatigued lower control arm assembly
Installation Notes and Tips
Install CB74364 at the front right lower position only on the listed Toyota applications. Verify ball joint orientation, torque all fasteners to factory specifications, and inspect adjacent suspension components before alignment. Because this assembly includes a press-in ball joint and bushings, proper installation practices are important for correct suspension operation.
Quality Assurance
MAS Chassis uses an industry-focused evaluation process for this suspension control arm and ball joint assembly to support smooth ride quality, directional stability, and predictable dynamics. CB74364 is built as a direct OE replacement for the specified Toyota Tundra and Toyota Sequoia applications.
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2022 | Toyota | Sequoia | Front Right Lower | — |
| 2021 | Toyota | Sequoia | Front Right Lower | — |
| 2021 | Toyota | Tundra | Front Right Lower | — |
| 2020 | Toyota | Sequoia | Front Right Lower | — |
| 2020 | Toyota | Tundra | Front Right Lower | — |
| 2019 | Toyota | Sequoia | Front Right Lower | — |
| 2019 | Toyota | Tundra | Front Right Lower | — |
| 2018 | Toyota | Sequoia | Front Right Lower | — |
| 2018 | Toyota | Tundra | Front Right Lower | — |
| 2017 | Toyota | Sequoia | Front Right Lower | — |
| 2017 | Toyota | Tundra | Front Right Lower | — |
| 2016 | Toyota | Sequoia | Front Right Lower | — |
| 2016 | Toyota | Tundra | Front Right Lower | — |
| 2015 | Toyota | Sequoia | Front Right Lower | — |
| 2015 | Toyota | Tundra | Front Right Lower | — |
| 2014 | Toyota | Sequoia | Front Right Lower | — |
| 2014 | Toyota | Tundra | Front Right Lower | — |
| 2013 | Toyota | Sequoia | Front Right Lower | — |
| 2013 | Toyota | Tundra | Front Right Lower | — |
| 2012 | Toyota | Sequoia | Front Right Lower | — |
| 2012 | Toyota | Tundra | Front Right Lower | — |
| 2011 | Toyota | Sequoia | Front Right Lower | — |
| 2011 | Toyota | Tundra | Front Right Lower | — |
| 2010 | Toyota | Sequoia | Front Right Lower | — |
| 2010 | Toyota | Tundra | Front Right Lower | — |
| 2009 | Toyota | Sequoia | Front Right Lower | — |
| 2009 | Toyota | Tundra | Front Right Lower | — |
| 2008 | Toyota | Sequoia | Front Right Lower | — |
| 2008 | Toyota | Tundra | Front Right Lower | — |
| 2007 | Toyota | Tundra | Front Right Lower | — |
