Maval 93347M Rack and Pinion Assembly

Maval Remanufactured Rack and Pinion for Sedona

The Maval 93347M remanufactured rack and pinion assembly is built for steering restoration on the 2007-2010 Kia Sedona. It is a direct-fit steering gear replacement with tie rod ends included and OE-style port and mounting specifications for service work that follows the original layout.

Key Features

• Remanufactured rack and pinion assembly from Maval
• Fits 2007-2010 Kia Sedona, N/A
• Part number 93347M for accurate ordering and lookup
• Steel and aluminum casting materials
• 2 mounting holes with 3.94 in. / 100.03 mm spacing
• 3.44 total turns lock to lock
• O-ring hose port type
• M14 x 1.5 pressure port thread size and M16 x 1.5 return port thread size
• Tie rod ends included

Product Details

Maval 93347M is a remanufactured rack and pinion assembly for the Kia Sedona steering system. It uses a 47.25 in. rack length, an 18.01 mm input shaft diameter, and a 30.15 mm input shaft length to match the original steering geometry. The assembly is specified with steel and aluminum casting materials, 2 mounting holes, and O-ring hose ports for OE-style hydraulic connection points. This part cross-references Cardone Reman 26-2435 for the same application.

The Maval remanufactured rack and pinion product line focuses on steering gear replacement parts built to restore factory-style steering response and fitment. For shoppers searching for a 2007-2010 Kia Sedona rack and pinion assembly, 93347M provides the key dimensions and port/thread details needed for a proper match.

Common Uses

• Restores steering control when the original rack has internal wear
• Addresses fluid leakage at rack seals or hydraulic ports
• Replaces a steering gear with excessive play or inconsistent response
• Helps correct steering noise caused by worn rack components
• Supports repair of a Kia Sedona steering system with OE-style dimensions

Installation Notes

Verify the vehicle year and steering configuration before installation. Confirm the mounting hole spacing, input shaft dimensions, and pressure/return port thread sizes against the original unit. Because tie rod ends are included, inspect related steering and suspension components during service and perform a professional alignment after installation.

Quality Assurance

Maval remanufactured steering components are processed to meet replacement-part service requirements for direct-fit repair work. Part number 93347M is cataloged for 2007-2010 Kia Sedona applications and should be matched to the original rack and pinion specifications before installation.
