Maval 93463M Rack and Pinion Assembly

Remanufactured Steering Rack for FJ Cruiser

The Maval 93463M remanufactured rack and pinion assembly is built for direct replacement service on the 2010-2014 Toyota FJ Cruiser. It is a steering rack and pinion assembly with inner tie rods included, aluminum casting construction, and OE-style port and mounting specifications for a precise service match.

Key Features

• Remanufactured rack and pinion assembly for steering system repair
• Fits 2010-2014 Toyota FJ Cruiser, N/A
• Inner tie rods included
• Aluminum casting material for the rack housing
• 2 mounting holes with 15.19 in. / 385.78 mm spacing
• 2.8125 total turns lock to lock
• 0.75 in. / 19.02 mm input shaft diameter
• O-ring hose port type with M16 x 1.5 pressure port and M17 x 1.5 return port threads
• Rack length: 48.94 in. / 1243.03 mm

Detailed Description

Maval Remanufactured Rack and Pinion 93463M is engineered for the steering layout used on the Toyota FJ Cruiser from 2010 through 2014. This assembly follows the original mounting and hydraulic connection dimensions, including a 2-hole mounting pattern, O-ring hose ports, and the specified pressure and return thread sizes. The 2.8125 turns lock to lock and included inner tie rods support a direct steering gear replacement for vehicles needing rack service. This part cross-references OE-style numbers such as 44200-35100 and 44200-35101 for the same application.

Common Repair Uses

• Steering play or looseness in the rack and pinion assembly
• Fluid leakage at the rack housing or hydraulic ports
• Binding, rough steering effort, or inconsistent steering response
• Wear in the internal rack mechanism or tie rod connection points
• Restoring steering feel on a 2010-2014 Toyota FJ Cruiser

Installation Notes and Tips

Verify the input shaft diameter, mounting hole spacing, hose port type, and thread sizes before installation. Inspect hydraulic lines, tie rod ends, and alignment components during replacement, and perform a professional wheel alignment after the steering rack is installed. Confirm vehicle application by year and model before ordering Maval 93463M.

Quality Assurance

Maval remanufactured steering components are rebuilt to service OE-style applications with attention to fitment, port configuration, and steering geometry. Part number 93463M is listed for the 2010-2014 Toyota FJ Cruiser application and is supported by the provided interchange references.
