Maval 94359M Rack and Pinion Assembly
| Brand | Maval 94359M |
|---|---|
| Type | Manual |
| Mounting Hole Quantity | 2 |
| Total Turns Lock To Lock | 3.5 |
| Casting Material | Aluminum |
| Distance Between Mounting Holes | 17.375 |
| Distance Between Mounting Holes | 441.33 |
| Input Shaft Diameter | 0.745 |
| Input Shaft Diameter | 18.92 |
| Input Shaft Length | 3.875 |
| Input Shaft Length | 98.43 |
| Rack Length | 1228.73 |
| Rack Length | 48.375 |
| Thread Length | 2.349 |
| Thread Length | 59.66 |
| Tie Rod Ends Included | Yes |
| Product line | Remanufactured Rack and Pinion |
| Fits | Saturn · 17 vehicles |
Remanufactured unit. Built as a replacement steering gear for listed applications.
Aluminum housing. Lightweight construction with the strength needed for steering service.
Tie rod ends included. Simplifies steering gear replacement with matched components.
Cross-references 23-1812 and 15797215 for the same application. See all 2.
Overview
This Maval remanufactured rack and pinion assembly is built for Saturn Vue applications with manual steering gear specifications. It is identified by part number 94359M and uses an aluminum housing with tie rod ends included.
Compatible With Saturn Vue fitment from 2002-2010, this rack and pinion assembly is a direct replacement option for vehicles listed in the fitment data. The 94359M part number is useful when matching the correct steering gear for the application.
Key Features
- Manual rack and pinion assembly for steering system replacement
- Remanufactured aluminum construction
- Includes tie rod ends
- 3.5 turns lock-to-lock for steering response
- Two mounting holes with listed OE-style dimensions
Product Details
Maval’s remanufactured rack and pinion line focuses on steering gear replacement units built to match the original application requirements. This assembly is specified with a 17.375-inch mounting hole spacing, a 48.375-inch rack length, and an input shaft diameter of 0.745 inch. The 94359M also lists a 3.875-inch input shaft length and 2.349-inch thread length, which are important reference points when verifying steering gear fitment.
For Saturn Vue owners replacing a worn steering gear, this rack and pinion assembly provides a manual steering configuration with the correct application coverage shown in the fitment data. The 94359M part number appears again here for easy catalog matching when comparing steering components.
This part cross-references Monroe Shocks & Struts (e.g., 23-1812, 15797215) for the same application.
Common Issues It Can Address
- Excessive steering play or looseness
- Uneven steering response during turning
- Fluid-free steering gear wear in manual rack applications
- Noise or binding from a worn steering rack assembly
- Incorrect steering feel caused by a deteriorated gear unit
Installation Notes
Verify the manual steering configuration, mounting hole spacing, input shaft dimensions, and rack length before installation. Confirm the vehicle application against the fitment data for Saturn Vue models listed for 2002-2010. Professional installation and a post-installation alignment are recommended after steering gear replacement.
Quality Assurance
This Maval remanufactured steering gear is part of a remanufactured rack and pinion product line designed for replacement use in steering systems. Part number 94359M should be matched carefully to the listed application before installation.
| Year | Make | Model | Submodel | Liters | Cylinders | Notes |
|---|---|---|---|---|---|---|
| 2010 | Saturn | Vue | XE | 2.4L | L4 | Remanufactured Manual R&P unit for Electric Power Steering System.; Remanufactured Rack and Pinion |
| 2009 | Saturn | Vue | XR | 2.4L | L4 | (All Models); Remanufactured Manual R&P unit for Electric Power Steering System.; Remanufactured Rack and Pinion |
| 2009 | Saturn | Vue | XE | 2.4L | L4 | (All Models); Remanufactured Manual R&P unit for Electric Power Steering System.; Remanufactured Rack and Pinion |
| 2009 | Saturn | Vue | Hybrid | 2.4L | L4 | (All Models); Remanufactured Manual R&P unit for Electric Power Steering System.; Remanufactured Rack and Pinion |
| 2008 | Saturn | Vue | Green Line | 2.4L | L4 | (All Models); Remanufactured Manual R&P unit for Electric Power Steering System.; Remanufactured Rack and Pinion |
| 2008 | Saturn | Vue | XE | 2.4L | L4 | (All Models); Remanufactured Manual R&P unit for Electric Power Steering System.; Remanufactured Rack and Pinion |
| 2007 | Saturn | Vue | Red Line | — | — | (All Models); Remanufactured Manual R&P unit for Electric Power Steering System.; Remanufactured Rack and Pinion |
| 2007 | Saturn | Vue | Green Line | — | — | (All Models); Remanufactured Manual R&P unit for Electric Power Steering System.; Remanufactured Rack and Pinion |
| 2007 | Saturn | Vue | Base | — | — | (All Models); Remanufactured Manual R&P unit for Electric Power Steering System.; Remanufactured Rack and Pinion |
| 2006 | Saturn | Vue | Base | — | — | (All Models); Remanufactured Manual R&P unit for Electric Power Steering System.; Remanufactured Rack and Pinion |
| 2006 | Saturn | Vue | Red Line | — | — | (All Models); Remanufactured Manual R&P unit for Electric Power Steering System.; Remanufactured Rack and Pinion |
| 2005 | Saturn | Vue | Red Line | — | — | (All Models); Remanufactured Manual R&P unit for Electric Power Steering System.; Remanufactured Rack and Pinion |
| 2005 | Saturn | Vue | Base | — | — | (All Models); Remanufactured Manual R&P unit for Electric Power Steering System.; Remanufactured Rack and Pinion |
| 2004 | Saturn | Vue | Base | — | — | (All Models); Remanufactured Manual R&P unit for Electric Power Steering System.; Remanufactured Rack and Pinion |
| 2004 | Saturn | Vue | Red Line | — | — | (All Models); Remanufactured Manual R&P unit for Electric Power Steering System.; Remanufactured Rack and Pinion |
| 2003 | Saturn | Vue | Base | — | — | (All Models); Remanufactured Manual R&P unit for Electric Power Steering System.; Remanufactured Rack and Pinion |
| 2002 | Saturn | Vue | Base | — | — | (All Models); Remanufactured Manual R&P unit for Electric Power Steering System.; Remanufactured Rack and Pinion |
