Maval 94480M Rack and Pinion Assembly

Maval 94480M Manual Rack and Pinion

The Maval 94480M is a remanufactured manual rack and pinion assembly for the Toyota Prius V with electric power steering system applications. Built with an aluminum casting and supplied with inner tie rods, it is specified for vehicles using 17-inch tires and is engineered for direct steering system replacement.

Key Features

• Remanufactured rack and pinion assembly for steering service
• Manual type rack for Prius V applications with electric power steering system
• Aluminum casting for the rack housing
• Inner tie rods included
• 2 mounting holes with 19.6875 in. / 500.062 mm mounting-hole spacing
• 3.125 total turns lock to lock
• Input shaft diameter: 0.788 in. / 20.015 mm
• Rack length: 42.75 in. / 1085.85 mm

Fitment

Compatible with Toyota Prius V steering applications. Fits 2012-2017 Toyota Prius V, N/A, for all models with 17 in. tires and remanufactured manual rack and pinion unit for electric power steering system.

This part cross-references Cardone Reman 1G-26018 and OE number 45510-47110 for the same application.

Product Details

The Maval Remanufactured Rack and Pinion line focuses on steering gear replacement units built to match application-specific dimensions and connection points. The 94480M follows that approach with a manual rack design, aluminum construction, and included inner tie rods for Toyota Prius V steering service. Use the listed measurements, including input shaft size, rack length, and mounting-hole spacing, to verify match-up before installation. The Maval 94480M is a direct-fit steering component for 2012-2017 Toyota Prius V models equipped with 17-inch tires.

Common Issues This Part May Address

• Excessive steering play or looseness
• Binding or rough steering effort
• Fluid-free steering gear wear in manual rack applications
• Noise from worn rack and pinion internal components
• Steering response problems related to a worn original rack assembly

Installation Notes

Confirm the vehicle’s tire size, steering configuration, and mounting dimensions before installation. Compare the input shaft diameter, rack length, and mounting-hole spacing to the original unit to ensure proper alignment and connection. After installation, perform a professional steering alignment and verify smooth steering travel from lock to lock.

Quality Assurance

This remanufactured steering assembly is built for application-specific replacement in Toyota Prius V models. Verify all fitment details against the original part number 94480M and the vehicle’s steering system before service.
