Maval 95313M Rack and Pinion Assembly

Maval Remanufactured Rack and Pinion for Mustang

The Maval 95313M remanufactured rack and pinion assembly is built for Ford Mustang steering service from 1999-2004. It is a direct-fit steering gear assembly with inner tie rods included, aluminum casting construction, and OE-style port and mounting dimensions for a precise replacement.

For Ford Mustang owners searching for a remanufactured rack and pinion assembly, this unit is built around the original steering layout and connection points. The Maval remanufactured rack and pinion line focuses on restoring steering function with application-specific fitment and measured component specifications.

Key Features

• Part number: 95313M
• Remanufactured rack and pinion assembly
• Fits 1999-2004 Ford Mustang
• Inner tie rods included
• Aluminum casting material
• 3 turns lock to lock
• Input shaft diameter: 0.73 in. / 18.62 mm
• Input shaft length: 2.8 in. / 71.12 mm
• Rack length: 48.5 in. / 1231.9 mm
• Pressure port thread size: 9/16 x 18
• Return port thread size: 5/8 in.-18
• Hose port type: Teflon
• Distance between mounting holes: 15.5 in. / 393.7 mm
• Number of mounting holes: 2

Detailed Description

This Maval rack and pinion assembly is a remanufactured steering gear for the Ford Mustang, covering 1999-2004 model years. It uses an aluminum housing and OE-style dimensions, including a 48.5-inch rack length, two mounting holes, and matching pressure and return port thread sizes for proper steering system connection. The assembly includes inner tie rods and is specified with 3 turns lock to lock for consistent steering response.

This part cross-references Cardone Reman 22-238 for the same application. The Maval 95313M is also associated with OE reference XR3Z-3504-BCRM.

Common Uses

• Replacing a worn or leaking steering rack in a Ford Mustang
• Correcting steering play or loose steering feel
• Addressing fluid seepage at rack seals or hose ports
• Restoring steering response after internal rack wear
• Servicing a Mustang steering system with OE-style connection points

Installation Notes and Tips

Verify the Mustang model year and steering connection details before installation. Confirm the pressure and return port thread sizes, input shaft dimensions, and mounting-hole spacing against the original unit to ensure proper alignment. After installation, perform a full steering and front-end inspection, then complete a wheel alignment.

Quality Assurance

Maval remanufactured steering components are rebuilt to application-specific specifications for direct replacement use. This rack and pinion assembly is produced with measured dimensions and included inner tie rods to support accurate fitment on Ford Mustang applications.
