Maval 96494M Power Steering Pump
Remanufactured Power Steering Pump for CTS
This Maval remanufactured power steering pump is built for 2004-2007 Cadillac CTS applications and is identified by part number 96494M. It features an aluminum housing, a threaded outlet, and a remote reservoir design for vehicles that use a hose-barb inlet and O-ring hose port connection.
The Maval Remanufactured Power Steering Pump line focuses on replacement units that match the original steering system layout, making it a practical choice for Cadillac CTS power steering pump replacement work where the reservoir is mounted remotely from the pump.
- Fits 2004-2007 Cadillac CTS, N/A
- Remanufactured power steering pump with aluminum housing
- Remote reservoir configuration
- Outlet attachment type: threaded
- Outlet thread size: 16x1.5
- Hose port type: O-ring
- Inlet attachment type: hose barb
- Pulley not included; pulley attachment type is press-on
- Mounting hardware not included
Use this pump when servicing a Cadillac CTS power steering system that requires a remote reservoir setup and a threaded outlet connection. Part number 96494M also cross-references Cardone Reman 21-5452 for the same application.
Common Replacement Needs
- Loss of power assist at the steering wheel
- Whining or groaning noise from the power steering system
- Fluid leakage at the pump outlet or hose connection
- Rough, inconsistent steering effort during turns
- Wear-related pump performance decline in a remote reservoir system
Installation Notes
For 2004-2007 Cadillac CTS fitment, transfer the pulley with the proper pulley removal and installation tool before installation. Verify the threaded outlet, 16x1.5 thread size, hose-barb inlet, and O-ring hose port connection match the original system before assembly. Because the pulley is not included, reuse only a serviceable pulley that matches the original press-on design.
Quality Assurance
This remanufactured Maval power steering pump is built as a direct replacement for the listed Cadillac CTS applications and is intended to restore proper hydraulic steering operation when the original pump has worn or failed.
| Brand | Maval |
|---|---|
| Part Number | 96494M |
| Position | Remanufactured Power Steering Pump |
| Pulley Included | No |
| Outlet Attachment Type | Threaded |
| Mounting Hardware Included | No |
| Housing Material | Aluminum |
| Outlet Quantity | 1 |
| Reservoir Included | No |
| Remote Reservoir | Yes |
| Reservoir Cap Included | No |
| Hose Port Type | O-ring |
| Inlet Attachment Type | Hose barb |
| Outlet Thread Size | 16x1.5 |
| Pulley Attachment Type | Press-on |
This part fits 6 vehicles. Search below:
| Year | Make | Model | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|
| 2007 | Cadillac | CTS | 2.8L | V6 | N/A | Pulley needs to be transferred with proper pulley removal/install tool.; Remanufactured Power Steering Pump |
| 2006 | Cadillac | CTS | 3.6L | V6 | N/A | Pulley needs to be transferred with proper pulley removal/install tool.; Remanufactured Power Steering Pump |
| 2006 | Cadillac | CTS | 2.8L | V6 | N/A | Pulley needs to be transferred with proper pulley removal/install tool.; Remanufactured Power Steering Pump |
| 2005 | Cadillac | CTS | 3.6L | V6 | N/A | Pulley needs to be transferred with proper pulley removal/install tool.; Remanufactured Power Steering Pump |
| 2005 | Cadillac | CTS | 2.8L | V6 | N/A | Pulley needs to be transferred with proper pulley removal/install tool.; Remanufactured Power Steering Pump |
| 2004 | Cadillac | CTS | 3.6L | V6 | N/A | Pulley needs to be transferred with proper pulley removal/install tool.; Remanufactured Power Steering Pump |
* Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
This part directly replaces or is cross-referenced with the following part numbers:
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
