Maval 9708M Power Steering Pump

Remanufactured Power Steering Pump for GM B-Body Applications

The Maval 9708M remanufactured power steering pump is built for select 1994-1996 Buick, Cadillac, and Chevrolet full-size rear-wheel-drive applications. It is a remote reservoir pump with a cast iron housing, threaded outlet, and O-ring hose port for service-focused replacement work.

Use this Maval remanufactured power steering pump when replacing a worn unit on 1994-1996 Buick Roadmaster, Cadillac Commercial Chassis, Chevrolet Caprice, or Chevrolet Impala models. The 9708M is specified without a pulley, so the original pulley must be transferred with the proper pulley removal and installation tool.

Key Features

• Remanufactured power steering pump from Maval
• Remote reservoir design
• Cast iron housing for durable service use
• Threaded outlet with 16x1.5 outlet thread size
• O-ring hose port type with hose barb inlet attachment
• No pulley included; press-on pulley attachment type
• No mounting hardware included
• One outlet configuration

Detailed Product Overview

The Maval 9708M is a remanufactured power steering pump engineered for vehicles using a remote reservoir setup. Its threaded outlet, O-ring hose port, and hose barb inlet match the hydraulic connection style used in the listed GM applications. This part cross-references Cardone Reman 20-864 for the same application.

Compatible With 1994-1996 Buick Roadmaster, 1994-1996 Cadillac Commercial Chassis, 1994-1996 Chevrolet Caprice, and 1994-1996 Chevrolet Impala. The 9708M part number is a direct reference point for buyers searching for a remanufactured steering pump for these GM platforms.

Common Problems This Part Can Address

• Loss of power steering assist
• Whining or groaning noise from the pump
• Fluid leakage at the pump housing or hose connections
• Heavy or inconsistent steering effort
• Wear-related pump performance decline

Installation Notes and Tips

Verify remote reservoir routing, outlet thread size, and hose port style before installation. Because the pulley is not included, transfer the original pulley using the correct pulley removal and installation tool. Mounting hardware is not included, so reuse or source the required fasteners as needed. Confirm the vehicle application against the listed fitment for Buick Roadmaster, Cadillac Commercial Chassis, Chevrolet Caprice, or Chevrolet Impala before service.

Quality Assurance

Maval remanufactured steering components are rebuilt for service replacement use and are cataloged by application and connection style to support accurate part selection. The 9708M is identified as a remanufactured power steering pump for the specified GM fitments, with interchange reference 26060578 for application matching.
