Metelli 04-0387 Drum Brake Wheel Cylinder - Rear
| Brand | Metelli 04-0387 |
|---|---|
| Position | Rear |
| Product Base Material | Cast Iron |
| Wheel Center Bore Diameter | 15.87 |
| Fits | Geo and Suzuki · 12 vehicles |
Cast iron construction. Provides durable, dependable braking performance.
Wheel cylinder. A hydraulic brake component for drum brake systems.
Cross-references AMS Automotive 4152, AP Exhaust 2590 and Gates 34041 for the same application. See all 27.
Rear Drum Brake Wheel Cylinder for Metro and Swift
Metelli 04-0387 is a rear drum brake wheel cylinder built with a cast iron body for hydraulic brake service on select Geo Metro and Suzuki Swift models. It is specified for rear applications and matches the listed bore diameter for direct-fit replacement use.
Key Features
- Cast iron product base material for brake hydraulic durability
- Wheel center bore diameter: 15.87
- Rear drum brake wheel cylinder application
- Direct replacement for select Geo Metro and Suzuki Swift rear brake systems
- Metelli part number 04-0387 for catalog and service reference
Detailed Description
Metelli 04-0387 is a drum brake wheel cylinder for rear brake hydraulics on 1989-1996 Geo Metro and 1989-1990, 1995-1996 Suzuki Swift models. The cast iron construction supports the demands of hydraulic drum brake operation, while the 15.87 wheel center bore diameter helps match the specified brake assembly requirements. This part number 04-0387 is a practical replacement choice when servicing rear wheel cylinder leakage, uneven brake response, or worn hydraulic components on Geo Metro and Suzuki Swift rear drum brake systems. This part cross-references Monroe Shocks & Struts (e.g., 172286) for the same application.
What It Is Used For
- Replacing a leaking rear wheel cylinder
- Restoring rear drum brake hydraulic pressure
- Addressing soft or inconsistent rear brake pedal feel
- Correcting brake fluid seepage at the wheel cylinder
- Servicing worn hydraulic components in rear drum brake assemblies
Installation Notes and Tips
- Fits 1989-1996 Geo Metro, rear
- Fits 1989-1990 Suzuki Swift, rear
- Fits 1995-1996 Suzuki Swift, rear
- Confirm bore diameter and rear drum brake configuration before installation
- Inspect brake shoes, drums, and hydraulic lines during service
- Bleed the brake system after installation to remove air from the hydraulic circuit
Quality Assurance
Metelli brake hydraulic components are cataloged for service replacement applications with attention to fitment and material specification. Part number 04-0387 is listed for the confirmed rear applications shown above.
| Year | Make | Model | # Doors | Position | Notes |
|---|---|---|---|---|---|
| 1996 | Geo | Metro | 2 Door | Rear | — |
| 1996 | Suzuki | Swift | — | Rear | — |
| 1995 | Geo | Metro | 2 Door | Rear | — |
| 1995 | Suzuki | Swift | — | Rear | — |
| 1994 | Geo | Metro | — | Rear | — |
| 1993 | Geo | Metro | — | Rear | — |
| 1992 | Geo | Metro | — | Rear | — |
| 1991 | Geo | Metro | — | Rear | — |
| 1990 | Geo | Metro | — | Rear | — |
| 1990 | Suzuki | Swift | 5 Door | Rear | — |
| 1989 | Geo | Metro | — | Rear | — |
| 1989 | Suzuki | Swift | — | Rear | — |
