Metelli 04-0905 Drum Brake Wheel Cylinder - Rear
| Brand | Metelli 04-0905 |
|---|---|
| Position | Rear |
| Product Base Material | Aluminum |
| Wheel Center Bore Diameter | 19.05 |
| Fits | Pontiac and Toyota · 15 vehicles |
Aluminum construction. Helps resist corrosion in brake hydraulics.
Wheel cylinder. A hydraulic brake component for drum brake systems.
Cross-references Dayco 72007, Federal Parts 4562 and 0 986 475 931 for the same application. See all 26.
Rear Drum Brake Wheel Cylinder for Toyota and Pontiac
Metelli 04-0905 is a rear drum brake wheel cylinder built with an aluminum base material and a 19.05 mm wheel center bore diameter. It is a direct-fit brake hydraulics component for select Toyota and Pontiac rear drum brake applications, including Toyota RAV4, Toyota Matrix, and Pontiac Vibe models.
Key Features
- Aluminum construction for brake hydraulic service applications
- 19.05 mm wheel center bore diameter
- Rear drum brake wheel cylinder design
- Fits select 2001-2008 Toyota and Pontiac rear applications
- Metelli part number 04-0905 for catalog lookup and ordering
Detailed Description
Metelli 04-0905 is a rear drum brake wheel cylinder for vehicles equipped with rear drum brakes. The aluminum base material supports brake hydraulic function in a compact OE-style replacement format, while the 19.05 mm bore specification matches the listed application requirements. This part is used on 2001-2003 Toyota RAV4, 2003-2008 Toyota Matrix, and 2003-2008 Pontiac Vibe rear brake systems with 3/4 in bore configuration. If you are searching for a rear drum brake wheel cylinder for Toyota Matrix, Pontiac Vibe, or Toyota RAV4 rear brakes, Metelli 04-0905 is the catalog reference to use.
This part cross-references Federal Parts 4562 for the same application.
What It Is Used For
- Replacing a leaking rear wheel cylinder in a drum brake system
- Restoring hydraulic pressure at the rear brakes
- Addressing soft or uneven rear brake response
- Correcting brake fluid seepage around the wheel cylinder area
- Servicing rear drum brake components on Toyota RAV4, Toyota Matrix, and Pontiac Vibe
Installation Notes and Tips
Verify rear drum brake configuration and bore size before installation. Confirm the vehicle application by year, make, model, and rear brake setup, especially on 2001-2003 Toyota RAV4 and 2003-2008 Toyota Matrix or Pontiac Vibe models. Inspect brake lines, shoes, and drums during service, and bleed the hydraulic system after replacement to remove air from the circuit.
Quality Assurance
Metelli brake hydraulics components are cataloged for specific OE-style applications, and this wheel cylinder is identified by part number 04-0905 for accurate fitment matching.
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2008 | Pontiac | Vibe | Rear | 3/4in bore |
| 2008 | Toyota | Matrix | Rear | 3/4in bore |
| 2007 | Pontiac | Vibe | Rear | 3/4in bore |
| 2007 | Toyota | Matrix | Rear | 3/4in bore |
| 2006 | Pontiac | Vibe | Rear | 3/4in bore |
| 2006 | Toyota | Matrix | Rear | 3/4in bore |
| 2005 | Pontiac | Vibe | Rear | 3/4in bore |
| 2005 | Toyota | Matrix | Rear | 3/4in bore |
| 2004 | Pontiac | Vibe | Rear | 3/4in bore |
| 2004 | Toyota | Matrix | Rear | 3/4in bore |
| 2003 | Pontiac | Vibe | Rear | 3/4in bore |
| 2003 | Toyota | Matrix | Rear | 3/4in bore |
| 2003 | Toyota | RAV4 | Rear | 3/4in bore |
| 2002 | Toyota | RAV4 | Rear | 3/4in bore |
| 2001 | Toyota | RAV4 | Rear | 3/4in bore |
