Metelli 05-0048 Brake Master Cylinder
Metelli 05-0048 Brake Master Cylinder
The Metelli 05-0048 is a new brake master cylinder built with a cast iron housing and dual outlet ports for direct hydraulic brake system service. It is listed for Volvo 240, DL, and GLE applications, including 1990-1993 Volvo 240 and 1984 Volvo DL and GLE.
Key Features
- Brand: Metelli New Master Cylinder line
- Part number: 05-0048
- Brake master cylinder for hydraulic brake systems
- Cast iron housing material
- 22.30/15.75 bore diameter
- Two outlet ports with M10 x 1.0 forward and rearward outlet sizes
- No reservoir included
- New condition
Product Details
Metelli’s New Master Cylinder line focuses on replacement hydraulic brake components for service work that requires accurate fit and dependable port sizing. This 05-0048 master cylinder uses a cast iron body and dual outlet configuration, with M10 x 1.0 forward and rearward outlets, to match the brake plumbing used on listed Volvo applications. It is a direct replacement choice for Volvo 240 brake master cylinder service and for Volvo DL and GLE master cylinder replacement needs.
This part cross-references FEL-PRO 1818 for the same application.
Common Problems This Part Can Address
- Brake pedal travel that has increased due to master cylinder wear
- External fluid leakage at the master cylinder body or outlet area
- Loss of hydraulic pressure in the brake system
- Soft or inconsistent brake pedal response
- Service replacement for a worn Volvo 240, DL, or GLE master cylinder
Installation Notes and Tips
Verify bore diameter, outlet thread size, and reservoir configuration before installation. Because no reservoir is included, transfer or source the correct reservoir arrangement for the vehicle as needed. After installation, bleed the brake system thoroughly and inspect all outlet connections for leaks. Confirm fitment against the vehicle’s brake plumbing and mounting points before final assembly.
Quality Assurance
Metelli supplies this brake master cylinder as a new replacement component for listed Volvo applications. The cast iron housing and specified outlet sizing support accurate service replacement for brake hydraulic repairs.
| Brand | Metelli |
|---|---|
| Part Number | 05-0048 |
| Position | New Master Cylinder |
| Housing Material | Cast iron |
| Master Cylinder Bore Diameter | 22.30/15.75 |
| Reservoir Included | No |
| Condition | New |
| Forward Outlet Size | M10 x 1.0 |
| Number of Outlets | 2 |
| Rearward Outlet Size | M10 x 1.0 |
This part fits 6 vehicles. Search below:
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 1993 | Volvo | 240 | N/A | New Master Cylinder |
| 1992 | Volvo | 240 | N/A | New Master Cylinder |
| 1991 | Volvo | 240 | N/A | New Master Cylinder |
| 1990 | Volvo | 240 | N/A | New Master Cylinder |
| 1984 | Volvo | DL | N/A | New Master Cylinder |
| 1984 | Volvo | GLE | N/A | New Master Cylinder |
* Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
This part directly replaces or is cross-referenced with the following part numbers:
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
