Metelli PA103 Engine Water Pump
| Brand | Metelli PA103 |
|---|---|
| Pulley Included | Yes |
| Gasket Or Seal Included | Yes |
| Housing Material | Aluminium |
| Impeller Material | Cast iron |
| Bearing Outside Diameter | 30 |
| Bearing Type | Ball/ball |
| Impeller Vane Quantity | 5 |
| Impeller Outside Diameter | 72.5 |
| New Or Remanufactured | New |
| Package Contents | Water pump, o-ring |
| Pulley Teeth Quantity | 26 |
| Pulley Width | 20.5 |
| Fits | Audi and Volkswagen · 44 vehicles |
New water pump. Includes a pulley and seal for a complete replacement.
Aluminium housing. Lightweight construction helps resist corrosion.
Cast iron impeller. Built for durable coolant circulation.
Cross-references Anchor 2050, Gates 20509 and Gates 21714 for the same application. See all 57.
Will it fit your vehicle?
Free return shipping if it doesn't fit.
Metelli PA103 Engine Water Pump
Metelli PA103 is a new engine water pump for timing belt driven applications, built with an aluminium housing and a cast iron impeller for the Audi and Volkswagen fitments listed below. It includes a pulley, gasket or seal, and O-ring for a direct replacement on supported vehicles.
Key Features
- New engine water pump for timing belt driven cooling systems
- Aluminium housing with cast iron impeller
- Pulley included with 26 teeth and 20.5 width
- Gasket or seal included for installation
- Ball/Ball bearing design with 30 mm bearing outside diameter
- 5-vane impeller with 72.5 mm outside diameter
- Package contents: water pump and O-ring
Detailed Description
The Metelli PA103 water pump is built for select Audi 100, Audi 200, Audi 4000, Audi Quattro, Audi 5000 Quattro, Audi 80 Quattro, Audi 90, Audi 90 Quattro, Audi Coupe, and Volkswagen Quantum applications that use a timing belt driven engine water pump. The design combines an aluminium housing with a cast iron impeller and ball bearings to support cooling system operation in the specified fitments. This part cross-references Gates (e.g., 20509, 21714) for the same application. Metelli PA103 is a direct replacement option for vehicles requiring the listed pulley and impeller specifications.
What This Water Pump Helps Address
- Coolant circulation problems caused by a worn pump
- Overheating from reduced coolant flow
- Noise or bearing wear from an aging water pump assembly
- Leaks at the pump sealing surface
- Timing belt service replacement on supported Audi and Volkswagen engines
Installation Notes and Tips
Verify engine code and timing belt drive configuration before installation. This pump is listed for vehicles up to May 1988 in several Audi applications, so confirm the exact build date and engine application before ordering. Replace the sealing surfaces carefully and inspect the timing belt system, pulleys, and coolant condition during service. Compatible With 1980-1989 Audi and Volkswagen timing belt driven engine water pump applications, including Audi 100, Audi 200, Audi 4000, Audi Quattro, Audi 5000 Quattro, Audi 80 Quattro, Audi 90, Audi 90 Quattro, Audi Coupe, and Volkswagen Quantum as listed in the fitment data.
Quality Assurance
Metelli PA103 is a new replacement part built to the listed specifications and fitment data for supported Audi and Volkswagen applications.
| Year | Make | Model | Liters | Cylinders | Fuel Type | Position | Notes |
|---|---|---|---|---|---|---|---|
| 1989 | Audi | 100 | 2.3L | L5 | GAS | N/A | Fits engines up to May 1988, driven by timing belt. |
| 1989 | Audi | 100 Quattro | 2.3L | L5 | GAS | N/A | Fits engines up to May 1988, driven by timing belt. |
| 1989 | Audi | 200 | 2.2L | L5 | GAS | N/A | Fits engines up to May 1988, driven by timing belt. |
| 1989 | Audi | 200 Quattro | 2.2L | L5 | GAS | N/A | Fits engines up to May 1988, driven by timing belt. |
| 1989 | Audi | 80 Quattro | 2.3L | L5 | GAS | N/A | Fits engines up to May 1988, driven by timing belt. |
| 1989 | Audi | 90 | 2.3L | L5 | GAS | N/A | Fits engines up to May 1988, driven by timing belt. |
| 1989 | Audi | 90 Quattro | 2.3L | L5 | GAS | N/A | Fits engines up to May 1988, driven by timing belt. |
| 1988 | Audi | 5000 Quattro | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1988 | Audi | 5000 Quattro | 2.3L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1988 | Audi | 80 Quattro | 2.3L | L5 | GAS | N/A | Fits engines up to May 1988, driven by timing belt. |
| 1988 | Audi | 90 | 2.3L | L5 | GAS | N/A | Fits engines up to May 1988, driven by timing belt. |
| 1988 | Audi | 90 Quattro | 2.3L | L5 | GAS | N/A | Fits engines up to May 1988, driven by timing belt. |
| 1988 | Volkswagen | Quantum | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1987 | Audi | 4000 Quattro | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1987 | Audi | 5000 Quattro | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1987 | Audi | 5000 Quattro | 2.3L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1987 | Audi | Coupe | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1987 | Audi | Coupe | 2.3L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1987 | Volkswagen | Quantum | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1986 | Audi | 4000 | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1986 | Audi | 4000 Quattro | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1986 | Audi | 5000 Quattro | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1986 | Audi | Coupe | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1986 | Audi | Quattro | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1986 | Volkswagen | Quantum | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1985 | Audi | 4000 | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1985 | Audi | 4000 Quattro | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1985 | Audi | Coupe | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1985 | Audi | Quattro | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1985 | Volkswagen | Quantum | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1984 | Audi | 4000 | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1984 | Audi | 4000 Quattro | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1984 | Audi | Coupe | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1984 | Audi | Quattro | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1984 | Volkswagen | Quantum | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1983 | Audi | 4000 | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1983 | Audi | Coupe | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1983 | Audi | Quattro | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1983 | Volkswagen | Quantum | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1982 | Audi | 4000 | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1982 | Audi | Coupe | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1981 | Audi | 4000 | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1981 | Audi | Coupe | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
| 1980 | Audi | 4000 | 2.2L | L5 | GAS | N/A | Timing Belt Driven Engine Water Pump |
