Will it fit your vehicle?
Confirm before you buy. Free return shipping if it doesn't fit.
Metelli PA1030 Engine Water Pump
| Brand | Metelli PA1030 |
|---|---|
| Pulley Included | Yes |
| Pulley Groove Quantity | 23 |
| Housing Material | Aluminium |
| Impeller Material | Techno-polymer |
| Bearing Outside Diameter | 30 |
| Bearing Type | Ball/ball |
| Impeller Vane Quantity | 9 |
| Impeller Outside Diameter | 62.5 |
| New Or Remanufactured | New |
| Pulley Width | 23.4 |
| Fits | Dodge, Fiat, and Jeep · 32 vehicles |
New water pump. Fresh replacement part for dependable cooling system performance.
Aluminium housing. Lightweight construction helps resist corrosion and wear.
Pulley included. Ready for a more complete installation right out of the box.
Cross-references Carlson 41203, Mopar 68385387AA and Nissens 941203 for the same application. See all 18.
Will it fit your vehicle?
Free return shipping if it doesn't fit.
Engine Water Pump for Fiat and Jeep Applications
The Metelli PA1030 engine water pump is a new replacement cooling component built for select Fiat and Jeep vehicles. It features an aluminum housing, a techno-polymer impeller, and a pulley already included for a direct-fit cooling system service.
- New engine water pump for cooling system repair
- Aluminum housing for durable pump construction
- Techno-polymer impeller with 9 vanes
- Ball/ball bearing design with 30 mm bearing outside diameter
- Pulley included with 23 grooves and 23.4 mm pulley width
- Impeller outside diameter: 62.5 mm
- Metelli PA1030 replacement part number for catalog lookup
Fitment Coverage
- Fits 2017-2020 Fiat 124 Spider, N/A
- Fits 2014-2020 Fiat 500L, N/A
- Fits 2016-2020 Fiat 500X, N/A
- Fits 2012-2019 Fiat 500, N/A
- Fits 2015-2018 Jeep Renegade, N/A
- Fits 2013-2016 Dodge Dart, N/A
Detailed Product Description
Metelli PA1030 is an engine water pump engineered for vehicles that rely on precise coolant circulation to maintain stable operating temperatures. The aluminum housing supports a rigid pump body, while the techno-polymer impeller and 9-vane design are specified for controlled coolant movement through the engine cooling circuit. The included pulley, 23-groove layout, and 23.4 mm pulley width make this a practical service part for applications that use a belt-driven pump assembly. This part cross-references Mopar 68385387AA and Nissens 941203 for the same application.
Use PA1030 when servicing cooling system wear on Fiat 124 Spider, Fiat 500L, Fiat 500X, Fiat 500, Jeep Renegade, and Dodge Dart applications. The Metelli PA1030 listing is a direct catalog reference for technicians and parts buyers searching by part number or vehicle fitment.
Common Repair Uses
- Coolant circulation loss caused by pump wear
- Overheating related to reduced water pump performance
- Noise or rough operation from worn pump bearings
- Leak-related cooling system service
- Replacement during timing or belt-driven cooling system maintenance
Installation Notes and Tips
Verify pulley groove count, pulley width, and engine application before installation. Inspect the belt drive, coolant condition, hoses, and adjacent cooling components during service to help confirm the repair. Always follow the vehicle manufacturer’s cooling system procedures, including proper coolant fill and bleed steps after installation.
Quality Assurance
Metelli supplies new aftermarket cooling components built to match listed vehicle applications and catalog specifications. PA1030 is a new part, not remanufactured, and is identified by OE-style interchange references for application matching.
| Year | Make | Model | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|
| 2020 | Fiat | 124 Spider | 1.4L | L4 | N/A | — |
| 2020 | Fiat | 500L | 1.4L | L4 | N/A | — |
| 2020 | Fiat | 500X | 1.3L | L4 | N/A | — |
| 2019 | Fiat | 124 Spider | 1.4L | L4 | N/A | — |
| 2019 | Fiat | 500 | 1.4L | L4 | N/A | — |
| 2019 | Fiat | 500L | 1.4L | L4 | N/A | — |
| 2019 | Fiat | 500X | 1.3L | L4 | N/A | — |
| 2018 | Fiat | 124 Spider | 1.4L | L4 | N/A | — |
| 2018 | Fiat | 500 | 1.4L | L4 | N/A | — |
| 2018 | Fiat | 500L | 1.4L | L4 | N/A | — |
| 2018 | Fiat | 500X | 1.4L | L4 | N/A | — |
| 2018 | Jeep | Renegade | 1.4L | L4 | N/A | — |
| 2017 | Fiat | 124 Spider | 1.4L | L4 | N/A | — |
| 2017 | Fiat | 500 | 1.4L | L4 | N/A | — |
| 2017 | Fiat | 500L | 1.4L | L4 | N/A | — |
| 2017 | Fiat | 500X | 1.4L | L4 | N/A | — |
| 2017 | Jeep | Renegade | 1.4L | L4 | N/A | — |
| 2016 | Dodge | Dart | 1.4L | L4 | N/A | — |
| 2016 | Fiat | 500 | 1.4L | L4 | N/A | — |
| 2016 | Fiat | 500L | 1.4L | L4 | N/A | — |
| 2016 | Fiat | 500X | 1.4L | L4 | N/A | — |
| 2016 | Jeep | Renegade | 1.4L | L4 | N/A | — |
| 2015 | Dodge | Dart | 1.4L | L4 | N/A | — |
| 2015 | Fiat | 500 | 1.4L | L4 | N/A | — |
| 2015 | Fiat | 500L | 1.4L | L4 | N/A | — |
| 2015 | Jeep | Renegade | 1.4L | L4 | N/A | — |
| 2014 | Dodge | Dart | 1.4L | L4 | N/A | — |
| 2014 | Fiat | 500 | 1.4L | L4 | N/A | — |
| 2014 | Fiat | 500L | 1.4L | L4 | N/A | — |
| 2013 | Dodge | Dart | 1.4L | L4 | N/A | — |
| 2013 | Fiat | 500 | 1.4L | L4 | N/A | — |
| 2012 | Fiat | 500 | 1.4L | L4 | N/A | — |
