Metelli PA1036 Engine Water Pump

Brand Metelli PA1036
Gasket Or Seal Included YES
Housing Material Aluminium
Impeller Material Cast Iron
Impeller Outside Diameter 74.75
Impeller Vane Quantity 6
New Or Remanufactured NEW
Package Contents Water Pump, O-ring
Fits Suzuki and Chevrolet · 21 vehicles

New water pump. Includes a gasket seal for a ready-to-install replacement.

Aluminium housing. Lightweight construction helps keep cooling components compact.

Cast iron impeller. Built with a 6-vane design for efficient coolant flow.

Cross-references Airtex AW9385, Anchor 9385 and Beck/Arnley 131-2257 for the same application. See all 40.

$37.75Free shipping
In stock · usually ships same day before 1pm CST
Step 1 — Confirm fitment
Free return shipping if it doesn't fit when you check fitment here first.
Select your vehicle to confirm fitment
Verify this part fits before purchasing β€” free returns if it doesn't
Step 2 — Quantity
Order total $37.75
Free shipping to the continental U.S.
Free returns within 60 days if it doesn't fit when fitment is verified.

Engine Water Pump for Suzuki and Chevrolet Applications

The Metelli PA1036 engine water pump is a new replacement water pump built with an aluminium housing and a cast iron impeller. It includes a gasket or seal and an O-ring in the package contents, making it a direct service part for cooling system repairs on select Suzuki and Chevrolet vehicles.

  • New engine water pump for cooling system service
  • Aluminium housing for durable fitment and corrosion resistance
  • Cast iron impeller with 6 vanes
  • Impeller outside diameter: 74.75
  • Gasket or seal included
  • Package contents: water pump and O-ring
  • Part number: PA1036

Fitment Details

Compatible with 1999-2008 Suzuki Grand Vitara, N/A. Compatible with 2002-2006 Suzuki XL-7, N/A. Compatible with 2001-2004 Chevrolet Tracker, N/A. Compatible with 2004 Suzuki Vitara, N/A.

This part cross-references Airtex AW9385 and Gates 42285 for the same application.

Product Overview

Metelli PA1036 is an engine water pump for vehicles that require a precise cooling system replacement. The aluminium housing supports stable mounting, while the cast iron impeller and 6-vane design are specified for coolant circulation in the engine cooling circuit. Use this water pump when servicing a leaking, noisy, or inefficient cooling system on Suzuki Grand Vitara, Suzuki XL-7, Chevrolet Tracker, or Suzuki Vitara models listed above. The PA1036 part number is also useful when matching an OE-style replacement by reference.

Common Repair Reasons

  • Coolant leakage from the water pump housing or seal area
  • Overheating caused by reduced coolant circulation
  • Noise from a worn pump bearing or impeller assembly
  • Cooling system service on a high-mileage Suzuki Grand Vitara or Chevrolet Tracker
  • Replacement of a failed pump during routine engine cooling maintenance

Installation Notes and Tips

Inspect the mating surface, coolant passages, and adjacent hoses before installation. Clean the mounting area thoroughly and verify that the included gasket or seal and O-ring seat correctly. Refill the cooling system with the correct coolant mixture and bleed air from the system according to the vehicle service procedure. Confirm pulley alignment and check for leaks after startup.

Quality Assurance

Metelli supplies new cooling system components built to match the listed application requirements. Verify fitment by year, make, and model before installation, and compare the PA1036 reference with the existing part number when replacing an original water pump.

This part fits 21 vehicles
Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
YearMakeModelLitersCylindersPositionNotes
2008SuzukiGrand Vitara2.7LV6N/A—
2007SuzukiGrand Vitara2.7LV6N/A—
2006SuzukiGrand Vitara2.7LV6N/A—
2006SuzukiXL-72.7LV6N/A—
2005SuzukiGrand Vitara2.5LV6N/A—
2005SuzukiXL-72.7LV6N/A—
2004ChevroletTracker2.5LV6N/A—
2004SuzukiGrand Vitara2.5LV6N/A—
2004SuzukiVitara2.5LV6N/A—
2004SuzukiXL-72.7LV6N/A—
2003ChevroletTracker2.5LV6N/A—
2003SuzukiGrand Vitara2.5LV6N/A—
2003SuzukiXL-72.7LV6N/A—
2002ChevroletTracker2.5LV6N/A—
2002SuzukiGrand Vitara2.5LV6N/A—
2002SuzukiXL-72.7LV6N/A—
2001ChevroletTracker2.5LV6N/A—
2001SuzukiGrand Vitara2.5LV6N/A—
2001SuzukiGrand Vitara2.7LV6N/A—
2000SuzukiGrand Vitara2.5LV6N/A—
1999SuzukiGrand Vitara2.5LV6N/A—
Directly replaces or cross-references 40 part numbers
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
Airtex — AW9385Anchor — 9385Beck/Arnley — 131-2257Dayco — DP511Four Seasons — 20767Gates — 42285GMB — 165-1200US Motor Works — US93851-932525-Jan51-2140252-86917400-8538117400-85830677321260662260665069039422859875025513151860069004ADK89110AWP-9325FWP1919FWP2015GWS-20AJ1518012Jan-25P7502PA1206PQ-899PWP9325S-26T1183VKPC96403WP-9325WP-9325SWP0826WPS-901
